Fireproof Signal Control Cable communication IEC 60331 - screened
Application
JE-H(ST)H FE180 E90 are halogen free and fireproof installation cables. They are suited for the industry- and building installations, public buildings and power stations. The cables are especially suitable for emergency and panic lighting and the like.
Construction
Conductor
Bare Cu, solid
InsulationFire-resistant, crosslinked
Conductor colourAccording to VDE 0815
Screen
Al-laminated tape with tinned Cu drain wire 0,8 mm
Outer sheath
Flame-retardant polyolefin compound according to VDE 0819 part 107, EN 50290-2-27 and VDE 0250-214, red
Technical data
Working temperature
Rated voltageMax. 225 V
Test voltage
| Conductor/conductor: | 500 V, 50 Hz |
| Conductor/screen: | 2000 V, 50 Hz |
Bending radius
-30° C to +90° C
6 x cable diameter
Approvals
IEC 60332-1, IEC 60332-3 cat. C, IEC 60331, IEC 60754, IEC 61034, CE approved, RoHS
