Help CenterVAV Cable PVC Insulated Power Cable
Related Products
-
China Best Price LSF Cu PVC SWA PVC Power CableNegotiableMOQ: 1 -
Best Quality 3 Core Steel Wire Armoured CableNegotiableMOQ: 1
-
Best Price Euro 4 Core Steel Wire Armoured CableNegotiableMOQ: 1
-
Medium Voltage XLPE Insulation PVC Sheathed SWA Power CableNegotiableMOQ: 1
-
High Quality 120sqmm Steel Wire Armoured CableNegotiableMOQ: 1
SWA pvc insulated cable
Steel wire armoured cable is suitable for using in power transmission lines with rated voltage up to and including 1KV.
Steel wire armoured cable Product Code & Description:
steel wire armoured cable Model, core number, nominal cross-section and the description:
Model |
Core number |
Nominal cross-section |
Description |
|
Cooper core |
Aluminum core |
|||
VV |
VLV |
1~5 |
1.5~240 |
PVC insulated PVC(Polyvinyl chloride ) sheathed power cable |
VV22 |
VLV22 |
4~240 |
PVC insulated PVC sheathed steel tape armored power cable |
|
YJV |
YJLV |
1.5~240 |
XLPE insulated PVC sheathed power cable |
|
YJV22 |
YJLV22 |
4~240 |
XLPE(Crosslinked polyethylene) insulated steel tape armored PVC sheathed power cable |
|
Min. Bending Radius For Installation
ITEM |
SINGLE CORE CABLE |
THREE-CORE CABLE |
||
NO ARMOR |
WITH ARMOR |
NO ARMOR |
WITH ARMOR |
|
|
Min. Bending Radius for Cable Installation
|
20D |
15D |
15D |
12D |
|
Min. Bending Radius Near Junction Box & Terminal Cable ( Bending Shall Be Controlled Carefully ) |
15D |
12D |
12D |
10D |
steel wire armoured cable Storage, transportation
1. Cable storage place should be dry and ventilated.
2. Cable tray is not allowed to place horizontally.
3. When storage avoid humidity and moisture into the cable core, both ends should not be
exposed to the air, uses cable caps to take the ends enclosed.
4. The cable tray is not allowed to place horizontally when transportation, as to avoid
crushing cables.
5. Lifting spreader should be used when lifting cables, pushing from the vehicle is strictly
prohibited.
6. Avoid the moisture into the cable core when transportation.
Technology property:
(1) Insulation core should bear the sparking test standard test standard GB/3048.13.
(2) The sheath should be closed tightened on the insulation. The surface of the sheath have to be smooth and its color should be well distributed.
(3) The finished cable should experienced soaking voltage testing as stipulated in the following table.
Table 1 :
Testing conditions |
Unit |
Property Nominal value |
The length of Sample |
m |
≥10 |
Soaking time |
H |
≥1 |
Water temperature |
deg |
20 ± 5deg |
Testing voltage value |
V |
3000 |
