Help Center2021year Top Quality Bare Conductor ACSR 70mm Code Name Beavier
Related Products
-
2021year Top Quality Bare Conductor ACSR 100mmNegotiableMOQ: 1 -
Hot Selling BS Standard ASTM Standard Aac Acsr ConductorNegotiableMOQ: 1
-
Turkey/Swan/Aster/Sparrow/Linnet AAC- ASTM All Aluminum ConductorNegotiableMOQ: 1
-
2021 No.1 Sales Multi-core AAC ACSR Bare ConductorNegotiableMOQ: 1
-
Aobest Cable Top Quality Aluminum Cable AACNegotiableMOQ: 1
Detailed Product Description
ACSR or ACSR cable or ACSR conductor used for Overhead electrical distribution and transmission lines for distributing power
Applications
Used as bare overhead transmission cable and as primary and secondary distribution cable. ACSR offers optimal strength for line design. Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity.
Construction
Aluminum alloy 1350-H-19 wires, concentrically stranded about a steel core. Core wire for ACSR is available with class A, B, or C galvanizing; ""aluminized"" aluminum coated (AZ); or aluminum-clad (AW). Additional corrosion protection is available through the application of grease to the corer or infusion of the complete cable with grease.
Specifications
ACSR bare conductor meets or exceeds the following ASTM specifications:
B-230 Aluminum Wire, 1350-H19 for Electrical Purposes
B-231 Aluminum Conductors, Concentric-Lay-Stranded
B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)
B-341 Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)
B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)
B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors, Steel Reinforced (ACSR)
Notes
· Resistance is calculated using ASTM standard increments of stranding and metal conductivity of 61.2% IACS for EC (1350) and 8% IACS for steel. AC (60Hz) resistance includes current dependent hysteresis loss factor for 1 and 3 layer constructions.
· Current ratings are based on 75oC conductor temperature, 25oC ambient, 2ft/s wind, 96/watts/sq.ft sun, 0.5 coefficients of emissivity and absorption.
size:
16mm2, 25mm2, 35mm2, 50mm2, 70mm2, 95mm2, 120mm2, 150mm2, 185mm2
|
Code Name |
Code Name |
Code Name |
Code Name |
High Strength Strandings |
|
Turkey |
Ibis |
Egret |
Curlew |
Grouse |
|
Swan |
Lark |
Flamingo |
Bluejay |
Petrel |
|
Swanate |
Pelican |
Gannet |
Finch |
Minorca |
|
Sparrow |
Flicker |
Stilt |
Bunting |
Leghorn |
|
Sparate |
Hawk |
Starling |
Grackle |
Guinea |
|
Robin |
Hen |
Redwing |
Bittern |
Dotterel |
|
Raven |
Osprey |
Tern |
Pheasant |
Dorking |
|
Quail |
Parakeet |
Condor |
Dipper |
Cochin |
|
Pigeon |
Dove |
Cuckoo |
Martin |
Brahma |
|
Penguin |
Eagle |
Drake |
Bobolink |
|
|
Waxwing |
Peacock |
Mallard |
Plover |
|
|
Partridge |
Squab |
Ruddy |
Nuthatch |
|
|
Ostrich |
Wood Duck |
Canary |
Parrot |
|
|
Linnet |
Teal |
Rail |
Lapwing |
|
|
Oriole |
Kingbird |
Cardinal |
Falcon |
|
|
Chickadee |
Rook |
Ortlan |
Chukar |
|
|
Brant |
Grosbeak |
|
|
|
ACSR BS standard
Please contact me freely; maybe I’ll give you good price: aobest(at)
whatsapp:+86 13310857673
Wechat: +86 13316918635
