All Aluminum Stranded Conductor (AAC)25mm2
Application:
Stranded 1350 aluminum conductors shown in this section of data are classified as follows:
Class AA For bare conductors usually used in overhead lines.
Class A For conductors to be covered with weather-resistant materials and for bare conductors where greater flexibility is required.
Compact strand conductor for use in bare overhead applications or for use with weather-resistant coverings or insulation is also available.
*Classes refer to stranding and are an indication of relative conductor flexibility, AA being the least flexible, C the most flexible.
Construction:
Aluminum 1350-H19 wires, concentrically stranded.
Specifications:
AAC bare conductors meet or exceed the following ASTM specifications :
B-230 Aluminum Wire, 1250-H19 for Electrical Purposes
B-231 Aluminum Conductors, Concentric-Lay-Stranded
B-400 Compact Round Concentric-Lay-Stranded Aluminum 1350 Conductors
Elative manufacturing standards:
We can supply this conductor according to different recognized standards, such as IEC61089, BS215, ASTM B231, CSA C49, DIN480201, JIS C3109, customer special specification also can be satisfied.
AAAC
ACSR
ACAR
AAAC
AAAC
ACSR
We provide the lowest price at high quality, if more info, please email me, sales009(at)
