High Quality ACSR Cable ACSR Bare Conductor Transmission Line
1.ACSR Conductor OEM as request
2.ISO 9001:2008,CCC
3.GB1179-83
4.Professional manufacturer in China for 18 years
5.Promote delivery, direct factory price
Standard:
According to IEC61089, and GB119783 also can do by standard of ASTM, BS, GB, DIN and AS/NZS or other standards.
Construction:
|
AAC |
7Al |
8Al |
19Al |
37Al |
|
ACSR |
6Al/1St |
7Al/1St |
12Al/7St |
30Al/7St |
|
AAAC |
8Al |
19Al |
37Al |
61Al |
Advantages:
a. Excellent electric and mechanical characteristics.
b. Good conductivity, Resistance chemical corrosion and heat-ageing,environment stress.
c. Unit volume light, Simple in structure.
d. Convenient to use, especially for laying across
Specifications of ACSR Cable:
|
Nominal Cross-section Area |
Conductor |
Calculation of Cross-section |
Outer Diameter |
Conductor Resistance at 20°C Max.(Ω/km) |
Tensile Force N |
Weight kg/km |
|||
| Aluminum | Steel | Aluminum | Steel | Total | mm | ||||
| 25/4 | 6/2.32 | 1/2.32 | 25.36 | 4.23 | 29.59 | 6.96 | 1.1313 | 9290 | 102.6 |
| 35/6 | 6/2.72 | 1/2.72 | 34.86 | 5.81 | 40.67 | 8.16 | 0.8230 | 12630 | 141.0 |
| 50/8 | 6/3.20 | 1/3.20 | 48.25 | 8.04 | 56.29 | 9.60 | 0.5946 | 16870 | 195.1 |
| 70/10 | 6/3.80 | 1/3.80 | 68.05 | 11.34 | 79.39 | 11.40 | 0.4217 | 23390 | 275.2 |
| 50/30 | 12/2.32 | 7/2.32 | 50.73 | 29.59 | 80.32 | 11.60 | 0.5692 | 42620 | 372.0 |
| 70/40 | 12/2.72 | 7/2.72 | 69.73 | 40.67 | 110.40 | 13.60 | 0.4141 | 58300 | 511.3 |
| 95/15 | 26/2.15 | 7/1.67 | 94.36 | 15.33 | 109.72 | 13.61 | 0.3058 | 15000 | 380.8 |
| 95/20 | 7/4.16 | 7/1.85 | 95.14 | 18.82 | 113.96 | 13.87 | 0.3019 | 37200 | 408.9 |
| 95/55 | 12/3.20 | 7/3.20 | 96.51 | 56.30 | 152.81 | 16.00 | 0.2992 | 78110 | 707.7 |
| 120/7 | 18/2.90 | 1/2.90 | 118.89 | 6.61 | 125.5 | 14.50 | 0.2422 | 27570 | 379.0 |
| 120/20 | 26/2.38 | 7/1.85 | 115.67 | 18.82 | 134.49 | 15.07 | 0.2496 | 41000 | 466.8 |
| 120/25 | 7/4.72 | 7/2.10 | 122.48 | 24.25 | 146.73 | 15.74 | 0.2345 | 47880 | 526.6 |
| 120/70 | 12/3.60 | 7/3.60 | 122.15 | 71.25 | 193.40 | 18.00 | 0.2364 | 98370 | 895.6 |
| 150/8 | 18/3.20 | 1/3.20 | 144.76 | 8.04 | 152.80 | 16.00 | 0.1989 | 32860 | 461.4 |
| 150/20 | 24/2.78 | 7/1.85 | 145.68 | 18.82 | 164.50 | 16.67 | 0.1980 | 46630 | 549.4 |
| 150/25 | 26/2.70 | 7/2.10 | 148.86 | 24.25 | 173.11 | 17.10 | 0.1939 | 54110 | 601.0 |
| 150/35 | 30/2.50 | 7/2.50 | 147.26 | 34.36 | 181.62 | 17.50 | 0.1962 | 65020 | 676.2 |
| 185/10 | 18/3.60 | 1/3.60 | 183.22 | 10.18 | 193.40 | 18.00 | 0.1572 | 40880 | 584.0 |
