Rating Voltage 6/6kv~26/35kv XLPE insulated yjv cable
Standard GB/T12706-2002, or design and produce as per client’s request.
Application performance: this products is suitable for power transmission and distribution rating voltage 6/6kv-26/35kv
- Max permissible operating temperature 90centigrade
- Max short circuit temperature(5 seconds at longest) shall not exceed 250centigrade
- The ambient temperature under installation should not below 0centigrade,if not, please heating in advance.
- Permissible bending radius ≥12 times of outer diameter of conductors
Model, Name and Application
|
Model |
Name |
Application |
|
|
Cu |
Al |
||
|
YJV |
YJLV |
XLPE insulated PVC sheathed power cable |
For laying aerial indoors , in-tunnel or cable trench |
|
YJY |
YJLY |
XLPE insulated PE sheathed power cable |
|
|
YJV22 |
YJLV22 |
XLPE insulated steel tape armored PVC sheathed power cable |
For laying indoors , intunnel or cable trench |
|
YJV23 |
YJLV23 |
XLPE insulated steel tape armored PE sheathed power cable |
|
|
YJV32 |
YJLV32 |
XLPE insulated thin steel wire armored PVC sheathed power cable |
For laying high-drop, well or underwater |
|
YJV33 |
YJLV33 |
XLPE insulated thin steel wire armored PE sheathed power cable |
|
|
YJV42 |
YJLV42 |
XLPE insulated thick steel wire armored PVC sheathed power cable |
Able to bear external mechanical forces, for laying in silo into sea |
|
YJV43 |
YJLV43 |
XLPE insulated thick steel wire armored PE sheathed power cable |
|
