Help CenterFull Bore Discharging Type Fully Welded Ball Valve GAQ61PPL
Related Products
-
DIN 901/ 902 Spring Loaded Full Lift Safety ValveUS$ 2 - 10MOQ: 10 Sets -
Dresser Safety Valve (GA900)US$ 2 - 10MOQ: 10 Sets
-
901/902 DIN Spring Loaded Full Lift Presure Safety ValveUS$ 2 - 10MOQ: 10 Sets
-
Spring Loaded Full Lift Pressure Safety ValveUS$ 2 - 10MOQ: 10 Sets
-
Spring Loaded Pressure Safety Valve, Lever Safety Relief ValveUS$ 2 - 10MOQ: 10 Sets
Application:
City Gas:gas outlet pipe,supply pipe for main line and all brach lines etc.
District heat supply:Outlet pipe,main line and brach line for large heat supply equipment.
Heat exchanger:on-off of pipe and all loops.
Steel plant:various fluid pipes,discharging pipe for exaust gas,supply pipe for gas,thermal power and fuel.
Various industrial equipment:various heat treatment pipes,pipe for all kinds of industrial gas and thermal power.
Features:
Outer leakage won't occur for welded ball valve.
Valve seat consists of teflon sealing ring strengthened by carbon fiber and belleville spring,so it can adjust well to change on pressure and temperature without any leakage risk within marked pressure and temperature range.
The whole process of sphere is tracked and detected with advanced computer and detector,so the process precision is very high,operation is very simple and easy,no bad interference.
Body material is same as material of pipe,when vehicles pass through the groud or even earthquake happens,the stress is evenly distributed without any deformation risk.
Sealing ring is made of PTFE containling 20% carbon,Ensure no leakage will happen.
Buried ground fully welded ball valve can be installed in small and shallow well being set on ground rather than large valve well,so the construction cost and project time can be saved a lot.
The length of valve body and height of stem can be designed in accordance with the requirement of project.
The service life can be more than 15 years when used at normal operational and using conditions.
Brief Introduction:
Full welded ball valve is a new develped ball valve,compared with ordinary ball valves,its performance is more reliable and has much longer service life,it has a wide application in the following industrial field :
Urban Gas Supply:Main and distribution pipelines.
Urban Central Heat Supply:Main and distribution pipelines.
Heat Exchanger.
Steel Factory:Pipelines for discharging waste gas,supplying coal gas and heat,etc.
Industrial Equipment:heat treatment pipelines,gas pipelines and thermal pipelines.
Construction Features:
1.Floating Ball/Trunnion Mounted.
2.Full bore/Reduced port.
3.Metal seal/Soft seal.
4.Fire Safe Design; Anti-static device; Blow-out proof stem.
5.Belleville spring ensure no leakage.
Product Rang:
Pressure Rating:150-600lb,1.6-4.0 Mpa
Connecting Size:1/2"-40",DN15-1000mm.
Connecting type:Thread,Welding,Flange,etc.
Applicable Temp(ºC):-19-150.
Applicable Medium:Water,Oil,Natural gas,etc.
Operating Mode:Lever,Gear,Electric,Pneumatic,etc.
Material Available:
Body: ST37.8 / A105 / LF2 / F304 / F316. Etc.
Ball : F304 / F316 ( Option upon request )
Seat: PTFE+C / Nylon / PEEK. Etc.
Main External Dimensions.
Short type |
Size |
L |
D |
D1 |
D2 |
DN50 |
300 |
50 |
60.3 |
114 |
|
DN65 |
300 |
65 |
76.1 |
140 |
|
DN80 |
300 |
80 |
88.9 |
165 |
|
DN100 |
325 |
100 |
114.3 |
216 |
|
DN125 |
350 |
125 |
141.3 |
219 |
|
DN150 |
490 |
150 |
168.3 |
355 |
|
DN200 |
580 |
200 |
219.1 |
356 |
|
DN250 |
550 |
250 |
273.1 |
457 |
|
DN300 |
630 |
300 |
323.9 |
508 |
|
DN350 |
762 |
337 |
355.6 |
559 |
|
DN400 |
840 |
387 |
406.4 |
660 |
|
DN500 |
1010 |
489 |
508 |
812 |
|
DN600 |
1140 |
591 |
609 |
1016 |
|
DN700 |
1346 |
686 |
711.2 |
1095 |
|
DN800 |
1524 |
781 |
812.8 |
1237 |
|
DN900 |
1727 |
874 |
914.4 |
1385 |
Long type |
Size |
A |
L |
D |
DN50 |
300 |
1000 |
110 |
|
DN65 |
300 |
1000 |
138 |
|
DN80 |
300 |
1000 |
165 |
|
DN100 |
300 |
1000 |
165 |
|
DN150(H) |
400 |
1000 |
200 |
|
DN150(G) |
400 |
1000 |
300 |
|
DN200 |
400 |
1000 |
380 |
|
DN250 |
400 |
1000 |
450 |
|
DN300 |
500 |
1200 |
550 |
|
DN400 |
500 |
1480 |
670 |
|
DN500 |
600 |
1765 |
800 |
|
DN600 |
650 |
1800 |
970 |
|
DN650 |
650 |
1850 |
1050 |
|
DN700 |
700 |
1950 |
1090 |
|
DN750 |
750 |
2000 |
1180 |
|
DN800 |
800 |
2150 |
1245 |
|
DN850 |
850 |
2200 |
1360 |
|
DN900 |
900 |
2400 |
1420 |
