Help CenterCE12804A-B00 Huawei CE12800 Series Data Center Switch AC Assembly Chassis,2*MPUA,3*SFU04A,3*PAC-2700WA
Related Products
-
CE12804A-B02 Huawei CE12800 Series Data Center Switch CE12804 AC Bundle2 AC Assembly ChassisNegotiableMOQ: 1 Unit -
PWR-C1-1100WAC Cisco Power Supply for Cisco 3850 Series Switches 1100W AC Config 1NegotiableMOQ: 1 Unit
-
PWR-C1-350WAC Cisco 3850 Series Power Supply PWR-C1-350WAC 350W AC Config 1 Power SupplyNegotiableMOQ: 1 Unit
-
PWR-C6-600WAC Catalyst 9000 Switch Power Supply Config 6 Hot-plug 600 WattNegotiableMOQ: 1 Unit
-
PWR-C2-1025WAC Catalyst 3650 Series Spare Power Supply 1025W AC Config 2NegotiableMOQ: 1 Unit
CE12804A-B00 Overview
CE12804A-B00 is CE12804 AC Bundle0 (AC Assembly Chassis, 2*MPUA, 3*SFU04A, 3*PAC-2700WA).
- CE12804A-B00 Specification
-
CE12804A-B00 Specifications Switching Capacity
(Tbit/s)45/
2581Forwarding Rate
(Mpps)17,280
Service Slots
4
Switching Fabric
Module Slots6
Fabric Architecture
Clos architecture, cell switching, VoQ, and distributed large buffer
Airflow Design
Strict front-to-back
Device Virtualization
Virtual System (VS)
Cluster Switch System (CSS)2
Super Virtual Fabric (SVF)3
Network Virtualization
M-LAG
TRILL
VxLAN routing and bridging
EVPN
QinQ in VXLAN
VM Awareness
Agile Controller
Network Convergence
FCoE
DCBX, PFC, and ETS
Data Center Interconnect
BGP-EVPN
Ethernet Virtual Network (EVN) for inter-DC Layer 2 network interconnections
Programmability
OpenFlow
ENP programming
OPS programming
Puppet, Ansible, and OVSDB plug-ins released on open source websites
Linux container for open source and customization programming
Traffic Analysis
NetStream
Hardware-based sFlow
VLAN
Adding access, trunk, and hybrid interfaces to VLANs
Default VLAN
QinQ
MUX VLAN
GVRP
MAC Address
Dynamic learning and aging of MAC addresses
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
MAC address limiting based on ports and VLANs
IP Routing
IPv4 routing protocols, such as RIP, OSPF, IS-IS, and BGP
IPv6 routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+
IP packet fragmentation and reassembling
IPv6
IPv6 over VXLAN
IPv6 over IPv4
IPv6 Neighbor Discovery (ND)
Path MTU Discovery (PMTU)
TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6
Multicast
IGMP, PIM-SM, PIM-DM, MSDP, and MBGP
IGMP snooping
IGMP proxy
Fast leave of multicast member interfaces
Multicast traffic suppression
Multicast VLAN
MPLS
Basic MPLS functions
MPLS VPN/VPLS/VPLS over GRE
Reliability
Link Aggregation Control Protocol (LACP)
STP, RSTP, VBST, and MSTP
BPDU protection, root protection, and loop protection
Smart Link and multi-instance
Device Link Detection Protocol (DLDP)
Ethernet Ring Protection Switching (ERPS, G.8032)
Hardware-based Bi-directional Forwarding Detection (BFD)
VRRP, VRRP load balancing, and BFD for VRRP
BFD for BGP/IS-IS/OSPF/Static route
In-Service Software Upgrade (ISSU)
Segment Routing (SR)
QoS
Traffic classification based on Layer 2, Layer 3, Layer 4, and priority information
Actions include ACL, CAR, and re-marking
Queue scheduling modes such as PQ, WFQ, and PQ + WRR
Congestion avoidance mechanisms, including WRED and tail drop
Traffic shaping
O&M
IEEE 1588v2
Packet Conservation Algorithm for Internet (iPCA)
Dynamic Load Balancing (DLB)
Dynamic Packet Prioritization (DPP)
Network-wide path detection
Microsecond-level buffer detection
Configuration
and MaintenanceConsole, Telnet, and SSH terminals
Network management protocols, such as SNMPv1/v2c/v3
File upload and download through FTP and TFTP
BootROM upgrade and remote upgrade
Hot patches
User operation logs
Zero-Touch Provisioning (ZTP)
Security
and Management802.1x authentication
RADIUS and HWTACACS authentication for login users
Command line authority control based on user levels, preventing unauthorized users from using commands
Defense against MAC address attacks, broadcast storms, and heavy-traffic attacks
Ping and traceroute
Remote Network Monitoring (RMON)
Dimensions
(W x D x H, mm)442 x
813 x
486.15
(11 U)Chassis Weight (empty)
(242 lb)
Operating Voltage
AC: 90V to 290V
DC: -38.4V to -72V
HVDC: 240VMax. Power Supply
6,000W
