LED Constant Voltage Waterproof Power Supply 36W
US$ 3.6 - 4.1
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Output Power:
1 - 50W
Output Type:
Single
Output Current:
3A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED Constant Voltage Waterproof Power SupplyUS$ 18 - 18.8MOQ: 10 Pieces -
LED Ultra-thin Plastic Shell Power SupplyUS$ 2.5 - 2.8MOQ: 100 Pieces
-
Cabinet Light Power SupplyUS$ 3.0 - 3.4MOQ: 100 Pieces
-
600W 24V Constant Voltage Waterproof LED Power Supply for Commercial UseNegotiableMOQ: 100 Sets
-
Constant Voltage Waterproof Led Power SupplyUS$ 1 - 1,000MOQ: 1 Piece
Output Power
1 - 50W
Output Type
Single
Output Current
3A
Output Voltage
12V
Input Voltage
220V
Features
* Constant pressure mode
* 100% full power burn-in test
* Suitable for dry or humid working environment
* Overvoltage, overload, short circuit and high temperature protection
* IP67 waterproof rating
Technical Parameters
| AC input range | 100-265Vac/50-60Hz | Operating temperature | -30℃ - +50℃，Tc：80℃ |
| Input surge current | Storage temperature | -40℃ - +80℃ | |
| Power Factor | 0.5-0.7 | Certification | EN61347-1; EN61347-2-13; SELV; SAA |
| Withstand voltage | 2000V/3750V | Dimensions | L187*W30*H20(mm) |
| protection | OCP,OVP,SCP-Auto Recovery | weight | 200g |
Product List
| Serial number | Output Power | Product number | Input voltage | The output voltage | Output current | Ripple and noise | effectiveness | Conventional input/output wire |
| 1 | 20W | VUO-020-005A1 | AC100-265V | DC5±0.5V | 4A max | 600mV max | 75% |
VDE H03VV-F 0.75mm²
enter：200mm
Output：200mm
|
| 2 | 30W | VUO-030-012A1 | AC100-265V | DC12±0.5V | 2.5A max | 240mV max | 82% | |
| 3 | 30W | VUO-030-024A1 | AC100-265V | DC24±0.5V | 1.25A max | 300mV max | 84% | |
| 4 | 36W | VUO-036-012A1 | AC100-265V | DC12±0.5V | 3.0A max | 240mV max | 82% | |
| 5 | 36W | VUO-036-024A1 | AC100-265V | DC24±0.5V | 1.5A max | 300mV max | 84% |
Note: The above are our standard products, parameters other than standard products can be designed according to customer requirements
