Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > LED Constant Voltage Waterproof Power Supply
US$ 18 - 18.8
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Output Power:
201 - 300W
Output Type:
Single
Output Current:
20.83A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED Constant Voltage Waterproof Power Supply 36WUS$ 3.6 - 4.1MOQ: 10 Pieces -
LED Ultra-thin Plastic Shell Power SupplyUS$ 2.5 - 2.8MOQ: 100 Pieces
-
Cabinet Light Power SupplyUS$ 3.0 - 3.4MOQ: 100 Pieces
-
Waterproof 120W IP68 Constant Voltage 12V 10A Switching Power Supply LED DriverUS$ 19 - 28MOQ: 50 Pieces
-
LED Screen Adjustable DC Power Supply for High Voltage Transformer Switching Power SupplyUS$ 800 - 1500MOQ: 1 Meter
Output Power
201 - 300W
Output Type
Single
Output Current
20.83A
Output Voltage
12V
Input Voltage
220V
Features
* Constant pressure mode
* 100% full power burn-in test
* Suitable for dry or humid working environment
* Overvoltage, overload, short circuit and high temperature protection
* IP67 waterproof rating
Technical Parameters
| AC input range | 185-265Vac/50-60Hz | Operating temperature | -30℃ - +60℃，Tc：80℃ |
| Input surge current | <25A/110Vac ; <15A/230Vac | Storage temperature | -40℃ - +80℃ |
| Power Factor | 0.5-0.7 | Certification | EN61347-1;EN61347-2-13;SELV |
| Withstand voltage | 2000V/3750V | Dimensions | L245*W95*H50(mm) |
| protection | OCP,OVP.SCP-Auto Recovery | weight | 1630g |
Product List
| Serial number | Output Power | Product number | Input voltage | The output voltage | Output current | Ripple and noise | effectiveness | Conventional input/output wire |
| 1 | 250W | VHO-250-012D3 | AC185-265V | DC12±0.5V | 20.83A max | 700mV max | 83% | VDE H03VV-F 0.75mm² enter：200mm Output：200mm |
| 2 | 250W | VHO-250-024D3 | AC185-265V | DC24±0.5V | 10.42A max | 700mV max | 84% |
Note: The above are our standard products, parameters other than standard products can be designed according to customer requirements
