Metal Wire Bending Fatigue Testing Instrument,cable tester
Summary --Metal Wire Bending Fatigue Testing Instrument,cable tester
Wire bending testing machine is suitable for the plug pinouts, power cord, USB cable, headphone cable, audio cable, headphone cable and other products wire rod bending tests or swing test. The specimen is fixed at fixture, and adding certain load, test swing around and through a few times, its outage, and view the total number of oscillations, it can automatically count, try to bend to break when not powering on, and automatically stop operation. Native UL817 related standards such as "cords-General safety requirements for components and power supply cords" provisions and general technical requirements for the headphone wire bending tests of the standard GB/T14471-93.
Main Parameters --Metal Wire Bending Fatigue Testing Instrument,cable tester
| Test stations | 6 groups |
| Bending angle | 0-180 ° adjustable |
| Test speed | 10-60/min |
| Control system | Digital with LCD screen |
| Counter | 0-999999 |
| Load weight | 50, 100, 200, 300, 500g |
| Machine weight | Approx 100kg |
| Power | AC220V, 50HZ |
Features --Metal Wire Bending Fatigue Testing Instrument,cable tester
1,The Cabinet with electrostatic paint treatment, according to various standards of design, machine design is reasonable, Fastening structure, safe, stable and accurate;
2, Counter can be preset, test, test automatic counting of conduction, reached number machine Stop with power off memory function, convenient and practical;
3, Speed knob adjustable, LCD display, set customers according to their requirements, the user-friendly design;
4, Manually adjustable bending angle, indicates the needle indicates the scale dial, to better regulation;
5, Six stations while working independently, respectively, counting, one line, the corresponding counter
Stop counting machine as usual test, improve testing efficiency;
6,Six groups of nonslip, easy to damage materials specially designed handle, clamping products more convenient, fast;
7, Test rods can be adjusted up and down, according to the standard requirements, and test better;
8, The distribution of weights with hook loading, multiple stacking, hanging more convenient.
Detailed Information-Metal Wire Bending Fatigue Testing Instrument,cable tester
3.4 Point Bending Testing Machine Wire and Cable Bending Testing Machine
Tooth brush bundle bending force tester Leather/Cloth Flex testing machine
Conpany Information
ZONHOW Test Equipment is a professional manufacturer of various kind of testing equipments over years.ZONHOW Test Equipment products are widely used in paper products,packaging ,ink printing ,adhesive tapes,bags,footwear,leather products,environment,toys baby product,
Hardware,electronic products,plastic products,rubber products and other industries,and applicable to all scientific research units,quality inspection institutions and academic fields.
