Help CenterPowder Coating Paint Film Impact Tester
Related Products
-
Well Designed Adhesive Tape - Holding Force Retention Test Machine Instrument Tester PriceUS$ 300 - 1,100MOQ: 1 Set -
Adhesion Tape Rolling Ball Method Initial Tack Ball Test MachineUS$ 130 - 390MOQ: 1 Set
-
China Supplier Adhesive Tape Test Equipment Electric Rolling WheelUS$ 590 - 890MOQ: 1 Set
-
Universal Pull off Initial Adhesion Testing Machine, High Precision Tape Initial Adhesion Test ApparatusUS$ 150 - 450MOQ: 1 Set
-
90 Degrees Adhesive Sticker / Film Stripping Force TesterUS$ 799 - 1,299MOQ: 1 Set
Use
Mainly used for testing the destruction degree after it hit, has the advantages of simple structure, convenient operation.
At a fixed weight of the heavy hammer falls in a certain height to impact test plate coated with a test sample, wallop to kg. Cm said.
Impact device includes a solid base for the pipe, conduit pipe shaft with slit and by using a suitable for the weight of the middle axis
Guide cylindrical load, there were marked to indicate the height of the corresponding reading when falling weight.
Type 2702 impact height of 0 to 50 cm, type 2703 impacter impact 0-100 cm in height.
Instrument base contains a mold base support, the size of the punch to suitable for the mold base,
This is important, it can prevent the plates on the mold base within the borders of the shear stress.
Conform to the standard
GB/T 1732-1993 film impact resistance measurement
Technical parameters
impact height |
0-50cm/0-100cm |
Scale unit |
1 cm |
Impact hammer |
1000 g |
punch diameter |
8 mm |
Mold base diameter |
15 mm |
Impact Depth |
2 mm |
Dimension |
200×200×800(1200) mm |
Weight |
15 kg |
1.Are your company a trading one or a factory ?
Factory + trade (integration),15 years focusing on test instruments field,7 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 120 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
