Wire Tensile Strength Tester , Tensile Testing Machine for Steel Wire Rod,
Webbing tensile testing machine
Wire is used hold, connect, pull, strengthen, and lift in many systems; ranging from bride support and concrete reinforcement, to small electronics. In these systems the wire may be required to hold loads up to 100kN or as small as 10N. Regardless of the application, it is critical to understand the tensile strength, working load, and elongation of the wire being used.
ZONHOW designs, manufactures, sells, and supports Testing Equipment that is configured to customer test requirements with test software, and accessories that help evaluate the mechanical properties of materials and components. These general purpose testing machines are used in research and development, and quality control applications to test the strength, elasticity, fatigue durability and properties of wire, cable and rope.
Applicable Testing Standards
- ASTM A82 Tensile Bending Steel Wire Test Equipment
- ASTM A185 Tensile and Bend Testing for Wire Reinforcements
- ASTM A370 Tensile Bend Strength Steel Test Equipment
- ASTM A391 Tensile Steel Chain Test Equipment
- ASTM A497 Tensile Welded Steel Wire Test Equipment
- ASTM A931 Steel Wire Rope Tension Test Equipment
- ASTM A938 Torsional Test of Wire
- ASTM A1064 Testing of Steel and Welded Wire Reinforcements
- ASTM B33 Tension Copper Wire Test Machines
- ASTM B557 Tension Cast Aluminum Magnesium Test Equipment
Recommended to use our model DZ-101 Universal Tensile Testing Machine
Specifications of Universal testing machine
Items |
Tensile Testing Machine |
Capacity |
100. 200. 500. 1000. 2000kg |
Unit Switchover |
G, KG, N, LB |
Display Device |
PC |
Resolution |
1/250,000 |
Accuracy |
±0.5% |
Max. Stroke |
800mm (including fixture) |
Test Speed |
0.1-500mm/min (adjustable ) |
Motor |
Panasonic Servo Motor |
Screw |
High Precise Ball Screw |
Elongation Accuracy |
0.001mm |
Power |
AC220V, 50HZ or customized |
Weight |
Approx.500kg / Tensile Testing Machine |
Accessories parts |
tensile clamp, computer system, English software CD, operation CD,user manual |
DZ-101 DZ-104 DZ-106 DZ-103
3/4 Point Bending Tester Touch Screen Tensile Tester Single Column Servo Tensile Tester Single Column Tensile Tester
Wire Tensile Strength Tester , Tensile Testing Machine for Steel Wire Rod, Webbing tensile testing machine
Wire Tensile Strength Tester , Tensile Testing Machine for Steel Wire Rod, Webbing tensile testing machine
Wire Tensile Strength Tester , Tensile Testing Machine for Steel Wire Rod, Webbing tensile testing machine
