Electronic Taber Abrasion Resistance Tester for Rubber Leather Textile Plastic
Product description:
Electronic Taber Abrasion Resistance Tester is to measure the abrasion resistance of rubbers (vulcanized thermoset rubbers and thermoplastic elastomers) that are subject to abrasive/frictional wear in their actual service, such as tires, conveyor drive belts, and shoe soles.
The main technical parameters:
Taber Abrasion tester
Specimen Size: |
ED:108mm ID:8mm ,3mm |
Abrasion Wheel: |
2"(max.45mm), 1/2"(W) |
Wheel Center Distance: |
63.5mm |
Rotating Speed: |
60/72 rpm |
Load: |
250g, 500g, 1000g |
Counter: |
LCD Touch screen, 0-999,999 Automatic shutdown |
Wheel and Specimens disk center space: |
37~38mm |
Machine Size: |
(L*W*H)530*320*310mm + vacuum cleaner |
Weight: |
18kg (Excluding vacuum cleaner) |
Power: |
1, AC220V/50Hz |
Wear index calculation formula: |
Abrasion loss weight/test turnover number×1000 |
Design criteria: |
DIN-53754, 53799,53109,52347, TAPPI-T476, ASTM-D1044,D3884, ISO-5470 |
Specimen Size: |
ED:108mm ID:8mm ,3mm |
Abrasion Wheel: |
2"(max.45mm), 1/2"(W) |
Wheel Center Distance: |
63.5mm |
Accessories:
- One vacuum cleaner machine
- One H10 wheel
- One box of abrasive papers for recondition the wheel
- Load 250,500 and 1000g
Our Lab:
Our company
Introduction:
HAIDA INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 24 years. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.
After-service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Why choose us?
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2.Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, Free replacement parts, even it's not from our factory's. What you need to do is to send us the controller.We can offer operation video and English operation muanual. We can provide video-con
