YES-2000D 2000kN used tyre pressure testing machine

FOB Price

US$ 2,000 - 3,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	kason		Place of Origin	Shandong, China
Model Number	YES-2000D		Power	Electronic

Product Description

Factory directly hot sales : YES-2000D 2000kN used tyre pressure testing machine

1. Application

Digital display compression testing machine mainly used for brick, cement, concrete construction material and other material compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.

2. Product description:

* Structure::mainly composed by main unit, oil source and measuring control system.

*Space adjusting way: Electric ball screw adjusting to realize the compression space adjusting

* Measuring control system:The machine adopts hydraulic loading, the electronic testing load. With digital display load, loading rate, keeping maximum load, overload protection and outage data keeping and other.

* Safety protection device:When the test foce exceed the 3% of the maximum test force ,overload protection, the oil pump motor stop.

3. Main Specifications

Model	YES-2000D		YES-3000D
Max test force	2000kN		3000kN
Test space adjusting way	Electric ball screw adjusting
Control way	Manual control loading process
Accuracy class	1 class
Test force range	4%~100%F·S
Test value accuracy	Better than ±1%
Oil cylinder stroke	50mm
Max distance between upper and lower plate	320mm	340 mm
Max distance between two columns	280mm
Upper and lower pressure plate	250×250mm		270*270mm
Main unit dimension	1000×500×1450mm
Power supply	2.0Kw/AC380V
Weight	1000Kg		1200kg

4,Configuration:

4.1 High strength main unit- 1 set

4.2 one-piece Oil source control cabinet-1 set

4.3 High precision pressure sensor-1pc

4.4 Digital display operation instrument- 1 set

4.5 Mini printer- 1 pc;

4.6 Compression grip-- 1 set
