Electric Quartz Far Infrared Heating Element for Vacuum Forming Heater

Far Infrared Quartz Radiation Heater provides medium wavelength radiator, they are comprised of a series of quartz tubes running parallel to each other within a highly reflective housing. Due to the short response time, Emitters are recommended for high temperature, cyclical or often interrupted processes. They are available as IR cassettes or single Infrared Tube, can be installed in the same way.

Resistance wire: chrome aluminum or Ni-Cr
Voltage: 110V/220V/230
Recommended radiation distance from heater is 100mm to 200mm

Main technical parameter:
1. Watt densities: 30 w/sq. inch (4.65 w/sq. cm)
2. Size(mm): 245x80x25, 245x60x25,122x60x25,122x122x25,60x60x25
3. Wave emission: 1 - 3 um
4. Housing: iron, stainless steel
5. Lifespan: >6000 hours

Quartz heater from China Topright Industrial Technology:

- Automotive: Primer coat, Color coat, Clear coat, Powder coat, Seat de-wrinkling, Head liner forming
- Plastics: Welding, Forming, Softening, Curing, Drying
- Printing: Ink drying, Silk Screening, Bindings, Glue drying
- Food: Baking, Browning, Dehydrating, Pasteurizing
- Electronics: Re-flow soldering, Water dry-off, Silk screening
- Textiles: Web Drying, Finishing, Pre-shrinking
- Glass-Ceramics: Heating safety glass, Drying mirrors, Drying fruit
