Infrared Quartz Heater Element for Heating Equipment

electric far infrared quartz heater panel for vacumm machine

(1)Power:12-480w  or as your demand
(2)Voltage:100-3000w or customized

Far Infrared Quartz Radiation Heater provides medium wavelength radiator, they are comprised of a series of quartz tubes running parallel to each other within a highly reflective housing. Due to the short response time, Emitters are recommended for high temperature, cyclical or often interrupted processes. They are available as IR cassettes or single Infrared Tube, can be installed in the same way.

Standard features :
Resistance wire: chrome aluminum or Ni-Cr
Voltage: 110V/220V/230
Recommended radiation distance from heater is 100mm to 200mm
Main technical parameter:
1. Watt densities: 30 w/sq. inch (4.65 w/sq. cm)
2. Size(mm): 245x80x25, 245x60x25,122x60x25,122x122x25,60x60x25
3. Wave emission: 1 - 3 um
4. Housing: iron, stainless steel
5. Lifespan: >6000 hours

Quartz heater from China Topright Industrial Technology:

Application:
- Automotive: Primer coat, Color coat, Clear coat, Powder coat, Seat de-wrinkling, Head liner forming
- Plastics: Welding, Forming, Softening, Curing, Drying
- Printing: Ink drying, Silk Screening, Bindings, Glue drying
- Food: Baking, Browning, Dehydrating, Pasteurizing
- Electronics: Re-flow soldering, Water dry-off, Silk screening
- Textiles: Web Drying, Finishing, Pre-shrinking
- Glass-Ceramics: Heating safety glass, Drying mirrors, Drying fruit

Our Exhibition in USA:

Order Guide:

RAQ:

1. Why the price is so low?
You are ordering directly from the factory.

2.Where is your factory located? How can I visit there?
Our factory is located in Yancheng City, Jiangsu Province, China, about 4 hours bus ride from Shanghai .All our clients, from home or abroad, are warmly welcome to visit us.

3.What type of payment do you have available?
A:We accept TT and L/C,as sample order,the Western nion,Money gram and Aliexpress is available.

4.How can I get some samples?
We are honored to offer you samples.

5.How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.
