Cartridge Heater Description:
Cartridge heaters is consist of a cylindrical stainless steel tube and thus provide a high corrosion prevention. The heating wire inside which is wound onto a ceramic core. The number of coils varies depending on the power. and provide a great uniform distribution of heat, which considerably increases the long life of the heater as well as prevents the oxidation of the heater wire even at high temperatures .The solids, liquids, and gases need to be heated by cartridge heater, transmit heat quickly by conduction if the producer of the heat (the cartridge) is in direct contact with the heat sink (any solid, liquid, or gas). Widely used for manufacturing plastic and rubber parts in the car industry or in the food processing industry, etc they are also commonly found in the chemical, electronics, medical equipment, packing and nuclear industries.Apart from our broad standard range we also develop and manufacture cartridge heaters according to your special demands.
Cartridge Heater Technical Detail:
Tube diameter: 6.5mm
Tube Material:SS304;SS316,SS321,NICOLOY800 etc.
Insulation Material:High-purity Mgo
Reisistance wire element:Ni-Cr or FeCr
Wattage density: high/middle/low(5-25w/cm2)
Lead Connection Option: Crimped or Swaged leads
Lead wire type: 10" Standard(Teflon/silicone high temperature frberglass)
Cartridge Heater Applications:
Liquid Immersion
Plastic Molds
Dies
Labeling
Medical Equipment
Platens
Packaging Equipment
Hot Stamping
Sealing
Injection Molding
Standard Items For Your Choice:
Specification:
| Product name | cartridge heater |
| Insulation | High-purity Mgo |
| Heating resistance | OCr20Ni80 wire |
| Tube material | SS304;SS316,SS321,NICOLOY800 |
| Min. dia. | 2.8mm |
| Lead option | Swaged or Crimped |
| Voltage | 24v |
| Lead wire | 500mm |
| Thermocouple | with or without |
Note:
1.We support OEM order,and print Brand or Logo on surface.
2.We can custom cartridge heaters specially(According to your size,voltage,power etc.)
Since 2001,Topright have been engaged in the development, design, production and sales in one of the sales of industrial technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development. Topright's products have been exported to Europe, America, Asia,Mid East etc. more than 90 countries. We supply different heating element for example silicone rubber heater, kapton heater, band heater, cartridge heater, tubular heater, thermocouple and ect. More details pls link online store:
How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.
Topright continuously strive to find ways of reducing our production costs, and passing the savings over to you.Superior quality, stylish designs, competitive price and perfect service won us honorable customers.Topright service includes regular and thorough inspections throughout the manufacturing process, eliminating the need to employ additional quality control inspectors.
