Supply Huawei Rectifier Modules R4850G2
The rectifier modules accept input voltage from 85Vac to 300Vac generates 53.5V for telecom applications. The operating temperature range is -40 Deg C to 75 Deg C . Customers can easily match the output with our DC-DC converters to generate different voltages for non-telecom applications.
Below is the product selection table and you may download the datasheet for details.
Part Number |
Input Voltage |
Output Voltage |
Output Power |
Efficiency |
Operating Temperature |
R4805G1 |
85-300Vac |
42-58Vdc |
270W |
94 % |
-40C to +75C |
R4815G1 |
85-300Vac |
42-58Vdc |
870W |
96 % |
-40C to +75C |
R4815N1 |
85-300Vac |
42-58Vdc |
1000W |
94 % |
-40C to +75C |
R4830G1 |
85-300Vac |
42-58Vdc |
1600W |
96 % |
-40C to +75C |
R4830G2 |
85-300Vac |
42-58Vdc |
2000W |
96 % |
-40C to +75C |
R4830N2 |
85-300Vac |
42-58Vdc |
1605W |
94 % |
-40C to +75C |
R4850G1 |
85-300Vac |
42-58Vdc |
3000W |
96 % |
-40C to +75C |
R4850G2 |
85-300Vac |
42-58Vdc |
3000W |
96 % |
-40C to +75C |
R4850N1 |
85-300Vac |
42-58Vdc |
2900W |
92 % |
-40C to +75C |
R4850N2 |
85-300Vac |
42-58Vdc |
3000W |
94 % |
-40C to +75C |
R48100G1 |
260-530Vac |
42-58Vdc |
6000W |
96 % |
-40C to +75C |
R33640G1 |
260-530Vac |
300-400Vdc |
15kW |
97% |
-40C to +75C |
R50030G1 |
260-456Vac |
300-500Vdc |
15kW |
95.8% |
-30C to +65C |
