Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus

Jiangsu Acrel Electrical Manufacturing CO.,LTD Verified Business License
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus thumbnail-1
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus thumbnail-2
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus thumbnail-3
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus thumbnail-4
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus thumbnail-5
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus photo-1
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus photo-2
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus photo-3
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus photo-4
Multifunction Digital Panel Meter/electric Smart Meter/multi Power Meter/digital Power Meter With Modbus photo-5
US$ 53 - 53 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Acrel
Place of Origin:
China
Model Number:
AMC72L-E4/KC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Acrel
Place of Origin China
Model Number AMC72L-E4/KC
Phase Three Phase
Output Voltage 220V
Operating Temperature -25℃~55℃
Dimensions 75*75mm
Display Type Other, LCD
Accuracy Class Class 0.5S
Measuring Energy Range 000000.00~999999.99kWh
Function
Meter type
Meter type
Optional function
Co-selection function
AMC72-E4/KC
AMC72L-E4/KC
Three phase voltage, Zero sequence voltage
Three phase current, Zero sequence current
Three phase active power, Total active power
Three phase reactive power, Total reactive power
Three phase apparent power, Total apparent power
Three phase Power factor, Total power factor
Frequency, Voltage phase angle, Voltage and current imbalance,Forward and reverse power
Four quadrant energy metering,System time display
1 channel RS485 interface / Modbus-RTU protocol and the statute DLT645.
①2DI+2DO+1Ep(K)
②4DI+2DO(K)
③Event record (SOE)
④Total harmonic measurement (H)
①③④

②③④
AMC96-E3/KC
AMC96L-E3/KC
①4DI+2DO+1Ep(K)
②2DI+2DO+1Ep(K)
③Event record (SOE)
④2-31th harmonic measurement (H)
⑤2-channel analog output (M)
①③④
②③④⑤
AMC96-E4/KC
AMC96L-E4/KC
AMC72-E/KC
AMC72L-E/KC
single-phase voltage，single-phase current
active power, reactive power, apparent power
Power factor
Frequency
Four quadrant energy metering,System time display
1 channel RS485 interface / Modbus-RTU protocol and the statute DLT645.
①2DI+2DO+1Ep（K）
②4DI+2DO（K）

Technical Parameters
Technical Parameters
Value
InputConnection

Single phase-2 wire,3 phase-3 wire,3 phase 4-wire

Frequency45-65Hz
Voltage

Rating:

Single-phase:AC 100V、400V

Three-phase:AC 3x57.7V/100V(100V)、3x220V/380V(400V)

3x380V/660V(660V)(96 size only)

Note:72 profile not suitable for high voltage application

Overload:1.2 fold rating(continuous):2 fold rating for 1 second
Power consumption:＜0.5VA
Current
Rating:AC 1A、5A
Overload:1.2 fold rating(continuous):10 fold rating for 1 second
Power consumption:＜0.5VA
OutputElectric energyOutput mode:open-collector photo-coupler pulse
Pulse constant:10000imp/kWh(settable),see wiring diagram for details
CommunicationRS485 port,Modbus-RTU protocol,DLT645 protocol(versions 09 and 97),baud rate 1200-38400
FunctionSwitching inputDry contact input,built-in power supply
Switching outputOutput mode:Relay normally open contact output
Contact capacity:AC 250V/3A、DC 30V/3A
Analog output
1-5V,4-20mA
Accuracy Class

Frequency:0.05Hz,Current、Voltage;0.2 class,Reactive

Power:1.0 class,Reactice Electric energy:1.0 class active

Power:0.5 class,active electric energy:0.5 class,2-31th harmonic

measurement:±1%

Power SupplyAC/DC 85-265V     Power consumption≤10VA
Security

Power frequency

withstand voltage

Between Power supply//Switching Output//Current input//voltage input and

Transmitting//Communication//Pulse Output//switching input AC 2kV 1min;

Between Power supply、switching output、Current input、voltage input AC 2kV 1min;

Between Transmitting、Communication、Pulse Output、switching input AC 1kV 1 min;

Insulation resistanceInput、Output end to machine enclosure＞100MΩ
EnvironmentTemperaturework:-25℃~+65℃ storage:-40℃~+80℃
Humidity≤93%RH Non-condensing
Altitude≤2500m
Recommended by seller
Split core current sensor with AC current 150-200A AKH-0.66-K-24$7.70 / Piece1 Piece
Acrel ADL10-E single phase 1 Pin din rail smart energy meter/PV solar power meter/ electrical meter$17.50 / Piece1 Piece
Acrel ADL3000-E 3 phase energy meter price RS485/three phase digital energy meter/three phase din rail energy meter$70.00 / Piece1 Piece
Acrel AC metering solution base station CE certificate AMC96L-E4/KC$74.00 / Piece1 Piece
Acrel multi circuit energy meters ADW210-D10-3S$238.00 / Piece1 Piece
Acrel 2G wireless communication Wireless energy meters ADW300-2G/C$124.00 / Piece1 Piece
Outline and size
Instrument type
length
width
height
72 square
75
75
94.5
96 square
96
96
77.8
