Universal Material Testing Machine 10 Ton Universal Testing Machine
0
|
Universal Material Testing Machine |
This tester is designed for conducting tensile, |
0
0
|
|
|
|
External Dimensions (CM): | |
75 x 70 x 170 | |
|
Package Dimensions (CM): | |
95 x 75 x 193 | |
Gross Weight(KG): | |
260 | |
Net Weight(KG): | |
210 (with mental base) |
0
0
Model |
GT-K01-1 |
GT-K01-2 |
Max. Capacity |
5KN,10KN, 20KN,Up to 300KN |
|
Display |
Computer display mode |
|
Force Resolution |
1/100,000 |
|
Force Accuracy |
≤+/-0.5% |
|
Stroke Resolution |
0.001 mm |
|
Extensometer Resolution |
0.001 mm |
|
Test Speed |
0.001-500mm/min |
0.001-1000mm/min |
Walking space |
1200mm (it can be custom-tailor according to their requirements) |
|
Force Unit Switch |
Kgf, N, Ibf, g, ton, Mpa |
|
Stop Mode |
Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function |
|
Machine Drive |
Servo motor drive, synchronous wheel and precision ball screw drive |
|
Power Supply |
AC 220V 50/60HZ 10A |
|
Dimensions |
75x70x170cm(WxDxH) |
|
Weight |
170kg |
|
SATRA TM5, TM53, TM52, TM51, TM108, TM113, TM117, TM118, TM120, TM123, TM149, TM162,
TM401, TM 411,TM 410, ASTMD 751/2209 /412/624 FIA 1206, BS5131- 3.7, 5.11, 5.13 ,
BS 5153-2.6, ISO22650, ISO 19958,ISO 3377-1, ISO 3377-2, ISO 11644, ISO 20866,ISO 20867, ISO19957, ISO20874, ISO20344-5.2.4, ISO 20345-5.3.1.2, ISO17698,ISO20875, ISO22777, ISO22776, ISO22654, ISO20863, ISO20876, ISO17695, ISO17697, ISO34-1 ,ISO36, ISO37, ISO 17708,ISO 17696,ISO17706,
ISO 22650, AS/NZS 2210.2-5.2.4, DIN 53331, GB/T 3903.8 , GB/T 3903.9 , GB/T3903.14, GB/T3903.20,GB/T3903.21, GB/T3903.22, GB/T 3903.23 , GB/T 3903.24, GB/T 3903.25, GB/T 3903.26, GB/T 3903.29 ,GB/T3903.32,GB/T 3903.39,GB/T 3903.40, GB/T 3903.43, GB/T 4689.20 ,
GB/T20991-5.2.4 ,GB 21148-5.3.1.2, GB/T 17928, GB/T529, GB/T528, GB/T532, GB/T1143, GB/T21396
QB/T 11413 ,QB/T 2711 ,QB/T2675, QB/T2883, QB/T4118,QB/T4198, HG/T 2726, HG/T 2877, HG/T4805
0
All kinds of material below can be tested on Universal Material Testing Machine 10 Ton Universal Testing Machine
0
- QIs your company a trading company or factory?
- AFactory + trade (integration), has 20 years focusing on test instruments field, 6 years exporting experience.
- QAfter an order is placed, when to deliver?
- AGenerally about 10-25days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.
- QWhat’s the payment term?
- AT/T,L/C and other payment terms could be negotiated.
- QWhat's the warranty and after-sales service?
- A12 months warranty. Feedback to you within 24h and help you to repair your problem controller freely, even it's not from our factory.
- QWhat the standards do you adopt?
- AWe have been adopting the world standards and regulation such as ISO, ASTM, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, and CSA.
- QWhat about the product' services and quality?
- AEach instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need. And our Main clients : SGS, BV and Intertek.
