Home > Products > Textile Testing Machine > Universal Shoe Wear Tester Stoll Abrasion Tester
Universal Shoe Wear Tester Stoll Abrasion Tester
- 500 Set / Sets per Month
- China port
- T/T Credit Card
Product Details
Brand Name: | GESTER | Place of Origin: | Fujian, China | Model Number: | GT-C15-2 |
Power: | Electronic |
Product Description
Universal Shoe Wear Tester Stoll Abrasion Tester
Stoll Abrasion Tester To determines the wear and abrasion resistance of fabric used in clothing, footwear and industrials. Supplied with surface abrasion head (inflated diaphragm method),flex abrasion head ,depth abrasion test device , flat abrasion (frosting) and pilling test device as well as necessary weights and initial supply of abrasive. Fitted with built-in timer and mechanical cycle counter.
0
0
- This machine equipped with accurate loop counter and timer. Digital counter can record the cycle index when the sample ruptured. And testers can preset the counter to stop before sample rupturing. Count down model can also be used in count the cycle index.
- To ensure accuracy of the rubber membrane when doing the surface abrasion test, this machine equipped with accurate pneumatic pressure control system.
- Test can be done automatically which can ensure not only the accuracy of repeat test result but also save operator’s time.
00
0
Model | GT-C15-1 | GT-C15-2 | ||||
Speed | 115±10 double stokes/ min | |||||
Stroke length | 25mm | |||||
Counter display | LCD | |||||
Power supply | AC 220V 50/60HZ | |||||
Dimensions | 480 x 360 x 715mm ( L x W x H ) | |||||
Weight | 50kg | |||||
Standards | ASTM D3885, D3886 | ASTM D3514, D3885, D3886 AATCC 119, 120 | ||||
Model | GT-C15-1 | GT-C15-2 | ||||
Standard accessories | Tension weights -5pcs
| Tension weights -5pcs | ||||
Press weights -5pcs | Press weights -5pcs | |||||
Micrometer calipers | Micrometer calipers | |||||
Flex Abrasion Test fixture - 1set | Flex Abrasion Test fixture - 1set | |||||
Flex Abrasion Blade Device -1set | Flex Abrasion Blade Device -1set | |||||
Surface Abrasion Test fixture -1set | Surface Abrasion Test fixture -1set | |||||
Power Line -1pc
| Edge & Fold Abrasion Test -1set | |||||
Flat abrasion (frosting) and pilling test fixture -1set | ||||||
Power Line -1pc | ||||||
Option accessories | Rubber membrane | |||||
ASTMD3514 Photograph | ||||||
ASTM D3514 Elastomeric Base Pad and Elastomeric Friction Pad |
0
All kinds of Yarn materials can be tested on the Universal Shoe Wear Tester Stoll Abrasion Tester
- QIs your company a trading company or factory?
- AFactory + trade (integration), has 20 years focusing on test instruments field, 6 years exporting experience.
- QAfter an order is placed, when to deliver?
- AGenerally about 10-25days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.
- QWhat’s the payment term?
- AT/T,L/C and other payment terms could be negotiated.
- QWhat's the warranty and after-sales service?
- A12 months warranty. Feedback to you within 24h and help you to repair your problem controller freely, even it's not from our factory.
- QWhat the standards do you adopt?
- AWe have been adopting the world standards and regulation such as ISO, ASTM, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, and CSA.
- QWhat about the product' services and quality?
- AEach instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need. And our Main clients : SGS, BV and Intertek.
