Color Check Light Box D65 Color Matching Cabinet
Application:
Colors appear differently under different lighting sources. To avoid/reduce the assessment error when performing color contrast, we can use of a Light Booth / Viewing Booth / Color Light Box to simulate different light sources to obtain an objective assessment of color and color difference, anytime, anywhere. The Color Viewing Cabinet / Color View Light Booth / Color assessment cabinet / Color Light Box can be applied to the industries that need to perform testing color difference as follows: as the premiere designer and manufacturer of color viewing and lighting products for the Graphic arts, Photographic, Textile, Dyeing, Packaging, Printing, Leather, Inks, Knitwear, Plastic, Automotive and Ceramics industries.
Feature:
1.Color assessment cabinet / Color Viewing Cabinet / Color View LightBooth render color more accurately. With 6 different light sources(D65, TL84, CWF, F, UV, U30), which can detect the metamerism.
2.Meets or exceeds major international standards for visual color evaluation including: ASTM D1729, ISO3664, DIN, ANSI and BSI.
3.Easy to operate by using individual switches for each light source.
4.Elapsed time meter for tracking optimal lamp replacement.
5.Automatically alternating among light sources.
6.No warm-up time or flickering which insures quick and reliable color judgment.
7.Economic power consumption and low heat generation for high light efficiency.
8.The dimension can be made by customized.
Product Image:
Key Specification:
Light source |
Color viewing booths Application |
Color temperature (K) |
Power(W) |
D65 |
International Standards Artificial Daylight |
6500 |
18 |
TL84 |
Applied to stores in Europe, Japan and china |
4000 |
18 |
CWF |
(Coll White Fluorescent) American standard |
4150 |
18 |
F/A |
“Sun-Setting Light Yellow” incandescent light source (imitation of sunset) |
2700 |
40 |
UV |
Viewing under ultraviolet light to detect and evaluate optical brighteners or fluorescent pigments |
Wavelength: 365nm |
20 |
U30 |
Warm White fluorescent ,American Standard |
3000 |
18 |
Models |
Configured light sources |
Weight |
Dimensions( L x W x H) |
|
GT-D08(4) |
D65. TL84. F/A . UV |
24kg |
71 x 40.5 x 57cm |
GT-D08(5) |
D65. TL84. CWF. F/A . UV |
28kg |
71 x 40.5 x 570cm |
GT-D08(6) |
D65. TL84. CWF. F/A . UV. U30 |
34kg |
71 x 53 x 57cm |
GT-D08(7) |
D65. TL84. CWF. F/A . UV. U30.INCA |
34kg |
710 x 530 x 570mm |
GT-D08(12) |
D65. TL84. CWF. F/A . UV. U30 |
65kg |
1310 x 600 x 800mm |
Fitting
Tube |
1set |
|
Power line |
1pc |
|
45o Standard grandstand |
1pc |
Optional |
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our
production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by GESTRE Instruments Co Ltd. Besides,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team
will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product
use training, each of our product provide video training to show you how to install & operate. We can arrange engineer
to train the operation of equipment to customer’s company when you need. Main clients : SGS, BV and Intertek. Our
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
