Drainage and electric conduit PVC pipe making machine
USD $30,000 - $30,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Shanghai
- T/T Credit Card
You May Like
-
plastic pvc pipe extruder machines making machine extrusion machine SJZ80
-
PVC PP PE PPR conduit water conduit pipe extruder making machine
-
Plastic PVC conduit electric water pipe extruder making machine extrusion line/ two cavity / Double pipe
-
pvc conduit pipe extruder making machine extrusion line/ plastic pipe making machinery
-
Plastic PVC Garden Soft fiber reinforce Pipe Making Machine/PVC garden hose production line
-
High performance PVC waterstop extruder making machine with high quality
Product Details
| Brand Name | FAYGO | Place of Origin | Jiangsu, China | |
| Certification | CE/ISO | |||
| Weight | 4000kg | Dimension(L*W*H) | 25m*2.5m*2.7m | |
| Voltage | customerized | Application | Pipe | |
| Condition | New | Power(W) | 120kw | |
| Automatic Grade | Automatic | Plastic Processed | PVC | |
| Screw Design | Double-screw |
Product Description
This machine is mainly used to produce PVC agricultural/water supply/drainage pipes, architectural water supply/drainage pipes, cable laying pipes etc. It can produce PVC pipes diameter from 16mm to 800mm.
This PVC pipe making machine adopts advanced design concept to ensure the efficient extrusion of PVC powder, combined with the unique concept of plasticization screw design to ensure uniformity of plastic extrusion, high capacity production.
Technical data
Technical data
| Model | pipe diameter | extruder | line speed | max output |
| FG63 | 16~63mm | SJZ65/132 | 1~20m/min | 250kg/h |
| FG160 | 50~160mm | SJZ65/132 | 1~6m/min | 250kg/h |
| FG400 | 110~400mm | SJZ80/156 | 0.2~6m/min | 380kg/h |
| FG630 | 315mm~630mm | SJZ92/188 | 0.2~3m/min | 800kg/h |
Components of PVC pipe making machine
a. Conical twin screw extruder:
Using the high efficient conical twin screws, specially designed for PVC power to ensure uniformed plasticization, high extrusion. Stable temperature controlling system can guarantee high quality pipe extrusion.
b. PVC pipe Mould:
Spiral type die head will ensure high speed extrusion and avoid the thermal decomposition of amorphous plastics and get high quality pipes. There is heating control system inside of the mould, high efficient, easy to extrude. Bronze calibrators can make the pipes fast calibrated and cooled.
c. Spraying and cooling tanks:
Rapid vacuum calibrating system allows the hot extruded pipes to be cooled in a very short time and obtain the final pipe diameter. Automatic temperature control system, pressure regulator, and vacuum control valve greatly enhance the pipe sizing and cooling performance as well as the production speed.
d. Haul off machine:
Adopts caterpillar type, which includes two-claw types, three-claw types, four-claw types, six-claw types, eight -claw types, ten-claw types, twelve-claw types etc, suitable for different sizes of pipes. Haul off caterpillar blocks are made of abrasion resistant rubber material, which can make a high and stable hauling speed.
e. Cutting machine:
Precision machine cutter is able to make flat, straight cuts into pipes at high speed. A powerful suction device gathers up waste scraps after cutting, thereby making it easier for users to clean the cutter.
6. Pipe belling machine:
Automatic pipe belling machine comes with 2 heating ovens to ensure pipe belling quality and productivity.
Equipment list of PVC pipe extrusion line
Compulsory devices of PVC pipe machine
1 | Material charge | |
2 | Conical twin screw extruder SJ-65/132, 80/156, 92/188 | |
3 | Pipe die head | |
4 | Vacuum calibrating tank | |
6 | 2-3-4-6-8-10-12 caterpillars hauling off machine | |
7 | Saw cutting machine or planetary cutting machine | |
Optional Devices | ||
1 | High speed hot and cold mixer | |
2 | Plastic crusher | |
3 | Plastic pulverizer | |
4 | Pipe socketing machine | |
5 | Industrial water chiller | |
6 | Air compressor | |
7 | Thermocontroller for die head | |
8 | Pipe printer | |
For more details about our PVC pipe making machine, welcome to contact with us. We will reply you in 24hours.
