Help CenterChina Manufacturer Plastic Container Bubble Tea Cup Sealing Machine
Related Products
-
Factory Sale Automatic Sauce Yogurt Small Cup Rotary Filling MachineUS$ 5,990 - 5,990MOQ: 1 Set -
CE Approved Fromage/jelly Cup Rotary Filling MachineUS$ 5,000 - 7,000MOQ: 1 Set
-
Shenhu Aluminum Tray Sealing Machine (for All Kinds of Shape)US$ 3,500 - 7,000MOQ: 1 Unit
-
Automatic Ice Cream Leben MONIN Cup Filling and Sealing MachineUS$ 7,000 - 12,000MOQ: 1 Set
-
SHENHU High Speed Plastic and Paper Cup Filling and Sealing Machine for Leben, Water, Cream, Juice, Yogurt, PowderUS$ 6,000 - 12,000MOQ: 1 Unit
The Linear Cup Filling Sealing Machine is specially designed for cup filled and sealed. The machine is a multi-functional high-speed full automatic machine for different sizes of cups according to clients' requirement. The machine is applied with world famous electrical and pneumatic components.
Features:
- The whole machine with advanced design, reasonable structure, reliable performance.
- Automatic operation, the production rate can be adjustable, simple and safe operation, increase productivity, reduce labor costs.
- Photocell eye calibration, ensure the accuracy of filling.
- Twice of sealing, the pressure of sealing can be adjustable. Can be sealed according to customer' requirements for easy to tear and not easy to tear, which embodies a higher level of human design.
- The sealing edges are smooth and flawless.
- The machine can be customized according to customer' needs and add other auxiliary functions.
Please don't be hesitate! Contact us and get more Bubble Tea Sealing Machine details!
Click for More Information !!!
| Item | China Supplier Mineral Water Cup Filling and Sealing Machine | |||
| Model | HTC-4 | HTC-6 | HTC-8 | HTC-10 |
| Output | 3000-4000 cups/h | 5000-6000 cups/h | 7000-8000 cups/h | 9000-10000 cups/h |
| Power | 3.5KW | 5KW | 6KW | 7.5KW |
| Filling Range | 50 to 300ml | 50 to 300ml | 50 to 300ml | 50 to 300ml |
Voltage |
220V 50Hz | 220V 50Hz | 220V 50Hz | 220V 50Hz |
| Air Consumption | 0.6 cubic meters/min | 0.7 cubic meters/min | 0.8 cubic meters/min | 0.9 cubic meters/min |
| Machine Size | 3300*710*1700mm | 3800*850*1700mm | 3800*710*1700mm | 4000*800*1700mm |
| Machine Weight | 700KG | 800KG | 1000KG | 1200KG |
Click for More Information !!!
Click for More Information !!!
Q: Can the ice cream, yogurt and K cup be filled and sealed at the same machine?
A: No, it can not be realized at one machine.
Q: Can the filling range be adjusted within a range?
A: Yes.
Q: Do we need to vacuum again after the nitrogen is gone?
A: No, you do not need.
Q: Can the mould, material barrel and filling head be dismantled?
A: Our filling head and barrel are welded and there is no way to remove them.
Q: Do we need add weighing equipment?
A: It can be blanking with measuring cups, screw cutting, no need of weighing equipment.
Q: We need double down the cup and add vibrating tray. Will the coffee powder sprinkle on the rim of the cup to affect the sealing effect?
A: The filling head is extended to the inside of the cup to fill, no coffee powder will be sprinkled on the edge of the cup, and the sealing effect will not be affected.
Q: We want better hygienic conditions and longer shelf-life.
A: We recommend the nitrogen filling function to extend the shelf life.
Q: We need quality assurance.
A: Our machines are exported to many countries, and the health quality has relevant certificates, and has many years of experience in making machines, so that you can rest assured that CE can be seriously sent to customers for reference.
Q: The width of the machine is too large to match our factory building.
A: The size of the machine can be customized as long as it is within reasonable limits.
Q: We want to fill the material of large particles, how to achieve?
A: Large particles are filled with measuring cups, if the powder is screw.
Q: What materials do you use?
A: Material contact parts are 304 stainless steel, if required, 316 stainless steel can also be matched, corrosion resistance.
Q: What are the brands of touch screen, PLC, motor and cylinder?
A: Touch screen: Taiwan Weilun. PLC: Japan 30. Motor: Taiwan Ming Chun. Cylinder: Domestic. (If you need other brands, you can also configure, the price will be a little different.)
Q: How long does it take to produce this machine?
A: About 40 days.
Click for More Information !!!
