2019 custom giant brushless motor for drone

FOB Price

USD $10 - $50 / Piece

5 Pieces(Min.Order)

Product Details

1. Applications:Medical equipment, industrial equipment, navigation models, electricaltools and mini household appliances

2. Operating Environment:-40~+120°C

3. Characteristics :

The following are our standard products, we also provide customized products and service.

4. Options:Lead wires length, shaft length, special coils, gearheads,bearing type, driver,encoder

5.Outline Drawing:

6.Photo:

7.Other Item:

Series	Dimension (mm)	Voltage (V)	No-load Speed (rpm)	No-Load Current (mA)	KV Value (rpm/V)	Torque Constant (mNm/A)
1308ZWW	Φ13*8	3.7	39000	700	10500	0.85
1511ZWW	Φ15*11	7.4	35000	400	4700	1.97
1709ZWW	Φ17*9	10	26000	110	2600	3.5
1814ZWW	Φ18*14	6.4	18500	270	2900	3.3
1814ZWW	Φ18*14	6.4	22000	350	3440	2.7
1816ZWW	Φ18*16	7.4	12000	160	1620	5.8
2010ZWW	Φ20*10	10	24000	110	2400	3.9
2015ZWW	Φ20*15	12	11300	80	940	9.9
2316ZWW	Φ23*16	12	19500	450	1625	5.8
2414ZWW	Φ24*14	12	6400	40	530	16.7
2814ZWW	Φ28*14	11.1	22000	650	2000	4.8
2820ZWW	Φ28*20	10.5	13500	450	1290	7.4
2824ZWW	Φ28*24	11.1	10200	400	920	10.3
2826ZWW	Φ28*26	14.8	13500	550	910	10.4
2828ZWW	Φ28*28	14.8	13000	650	880	10.8
2830ZWW	Φ28*30	14.8	13300	750	900	10.6
2914ZW	Φ29*14	24	5500	100	230	40
2914ZWW	Φ29*14	24	5500	100	230	40
3212ZWW	Φ32*12	12	22000	500	1833	5.0
3216ZWW	Φ32*16	12	3200	500	270	35
3517ZWW	Φ35*17	24	4450	60	185	50
3518ZWW	Φ35*18	12	10000	500	830	11.3
3825ZWW	Φ38*25	14.8	10400	560	700	13.5
3828ZWW	Φ38*28	24	29000	700	1200	7.8
4316ZWW	Φ43*16	12	4350	180	360	26
4321ZWW	Φ43*21	24	6700	200	280	34
4326ZWW	Φ43*26	24	6100	300	260	37
4834ZWW	Φ48*34	22.2	10400	1300	470	20
6133ZWW	Φ61*33	22.2	6400	930	290	33
8724ZWW	Φ87*24	36	3600	200	100	95
