100W 4200mA Waterproof LED Current Dimming Driver

100W 4200mA Waterproof LED Current Dimming Driver thumbnail-1
100W 4200mA Waterproof LED Current Dimming Driver photo-1
US$ 16 - 18 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMCFLEX
Place of Origin:
China
Model Number:
APMS-100C-4200
Contact Supplier Request Quote Chat Now
Changzhou AMCFLEX Technology Co Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name AMCFLEX
Place of Origin China
Model Number APMS-100C-4200
Output Power 51 - 100W
Output Type Single
Output Current 4200mA
Output Frequency 50/60hz
Output Voltage 12-24VDC
Input Voltage 220V

Product Features:
Wide AC input (up to 305VAC)
Protections: Short circuit / Over current / Over voltage / Over temperature
Built-in active PFC function
High efficiency up to 94%
IP67 / IP65 design for indoor or outdoor installations
Output current fixed
Cooling by free air convection
Suitable for dry, damp, and wet location
Suitable for LED lighting and street lighting applications
Meet 4kV +6KV surge immunity level (IEC61000-4-5)
Class 2 power unit / Pass LPS


Technical Specs:

1.   Input Voltage: 200-277VAC, Typical 220VAC

2.   Input voltage range: 176-305VAC

3.   Input Frequency: 50/60HZ

4.   Input Frequency range: 47-63HZ

5.   Max input vcurrent:1.0A Max, Vin=200VAC, rated load

6.   Input Inrush current

7.   PF>0.95, Vin=200-240VAC, rated load

8.   THD


Model NO Input voltage Output voltage Output current output power Efficiency

Dimension/mm
APMS-100C-700 200-277VAC 71-142VDC 700mA 100W 92% 156x51x38
APMS-100C-1050 200-277VAC 48-96VDC 1050mA 100W 92% 156x51x38
APMS-100C-1400 200-277VAC 36-72VDC 1400mA 100W 92% 156x51x38
APMS-100C-2100 200-277VAC 24-48VDC 2100mA 100W 92% 156x51x38
APMS-100C-2800 200-277VAC 18-36VDC 2800mA 100W 92% 156x51x38
APMS-100C-3500 200-277VAC 14-28VDC 3500mA 100W 92% 156x51x38
APMS-100C-4200 200-277VAC 12-24VDC 4200mA 100W 92% 156x51x38


Dimension:150(L)*51 (W)*38(H)mm

Packing: 0.65KG/PC, 350x310x260mm, 20pcs /14.5Kg / 0.02CBM /CTN
