150W 700mA 108-216VDC LED Street Light Moisture-proof Current Drivers

150W 700mA 108-216VDC LED Street Light Moisture-proof Current Drivers thumbnail-1
150W 700mA 108-216VDC LED Street Light Moisture-proof Current Drivers thumbnail-2
150W 700mA 108-216VDC LED Street Light Moisture-proof Current Drivers photo-1
150W 700mA 108-216VDC LED Street Light Moisture-proof Current Drivers photo-2
US$ 18 - 20 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMCFLEX
Place of Origin:
China
Model Number:
APMS-150C-700
Contact Supplier Request Quote Chat Now
Changzhou AMCFLEX Technology Co Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name AMCFLEX
Place of Origin China
Model Number APMS-150C-700
Output Power 101 - 200W
Output Type Single
Output Current 700mA
Output Frequency 50/60hz
Output Voltage 108-216VDC
Input Voltage 220V

Product Features:
Wide AC input (up to 305VAC)
Protections: Short circuit / Over current / Over voltage / Over temperature
Built-in active PFC function
High efficiency up to 94%
IP67 / IP65 design for indoor or outdoor installations
Output current fixed
Cooling by free air convection
Suitable for dry, damp, and wet location
Suitable for LED lighting and street lighting applications
Meet 4kV +6KV surge immunity level (IEC61000-4-5)
Class 2 power unit / Pass LPS


Technical Specs:

1.   Input Voltage: 200-277VAC, Typical 220VAC

2.   Input voltage range: 176-305VAC

3.   Input Frequency: 50/60HZ

4.   Input Frequency range: 47-63HZ

5.   Max input vcurrent:1.0A Max, Vin=200VAC, rated load

6.   Input Inrush current

7.   PF>0.95, Vin=200-240VAC, rated load

8.   THD


Model NO Input voltage Output voltage Output current Output power Efficiency

Dimension/mm
APMS-150C-700 200-277VAC 108-216VDC 700mA 150W 92% 180x63x40
APMS-150C-1050 200-277VAC 71-142VDC 1050mA 150W 92% 180x63x40
APMS-150C-1400 200-277VAC 54-108DC 1400mA 150W 92% 180x63x40
APMS-150C-2100 200-277VAC 36-72VDC 2100mA 150W 92% 180x63x40
APMS-150C-2800 200-277VAC 27-54VDC 2800mA 150W 92% 180x63x40
APMS-150C-3500 200-277VAC 14-28VDC 3500mA 150W 92% 180x63x40
APMS-150C-4200 200-277VAC 18-36VDC 4200mA 150W 92% 180x63x40
APMS-150C-5000 200-277VAC 15-30VDC 5000mA 150W 92% 180x63x40


Dimension:180(L)*63 (W)*40(H)mm

Packing: 0.8KG/PC, 350x310x260mm, 16pcs / 14.3 Kg /0.02CBM/CTN
