General Information:
SXFA-IV is portable analyzer designed for analyzing current transformers and voltage transformers of protection or measurement use, which is suitable for laboratory and on-site test.
Features:
- 5.7’ LCD screen, display clearly even under sunshine.
- Rotating photoelectric mouse, easy to operate.
- Build in printer to print test result automatically after testing completed.
- Full functions, satisfy all kinds of CT(protection CT, measuring CT, TP) test requirements, such as excitation characteristic test, turn ratio, polarity, secondary winding resistance, secondary burden, ratio error, angular difference and etc. Also it can be used to test excitation characteristic, turn ratio, polarity, secondary winding resistance, ratio error, angular difference and etc all kinds of PT.
- Auto test CT/PT parameters on knee point voltage/current, 5% and 10% deviation curve measurement, Accuracy limit factor (ALF), safety factor (FS), second time constants (Ts), residual magnetism factor(Kr), saturated and unsaturated inductance.
- Accurately measure ratio error and angular error. Max. Ratio error ±0.05% is permitted. Max. Angular error ±2min if permitted. It can measure 0.2S class CT and turns ratio range is 1-40000.
- Complied with IEC 61869-1 to 3 standards of all kinds of CT/PT.
- Using variable frequency method can make CT test when keen point is up to 60kV.
- Easy to use. To test CT DC resistance, excitation and polarity only by one button. All CT tests adopt same one connect method except load test.
- To export test data by U disk.
- 1000 groups’ data storage, data can be saved even power failure.
- Friendly interface, English graphical interface.
- Small size and portable, weight less than 10KG.
Main Test Functions:
Output | 0~180Vrms,12Arms,36A(peak value) | ||
Voltage measurement precision | ±0.1% | ||
CT Turns Ratio | Range | 1~40000 | 1~30000 |
Precision | ±0.05% | ±0.2% | |
PT Turns Ratio | Range | 1~40000 | 1~30000 |
Precision | ±0.05% | ±0.2% | |
Phase measurement | Precision | ±2min | ±5min |
Resolution | 0.5min | 0.5min | |
Secondary Winding Resistance | Range | 0~300Ω | 0~300Ω |
Precision | 0.2%±2mΩ | 2%±2mΩ | |
AC Load Measurement | Range | 0~300VA | |
Precision | 2%±0.2VA | ||
Power Supply | AC220V±10%,50Hz | ||
Working Conditions | Temperature: -10οC~50οC, Humidity: ≤90% | ||
Size & Weight | 365 mm×290 mm×153mm Weight<10kg | ||
Wuhan Sansion Power Equipment Manufacturing Co., Ltd. is a modern company focusing on design and manufacturing of test and measurement instruments. Our company covers 5,000 square meters with 120 employees.
Sansion has more than 20 years’ experience of producing electrical test sets and solutions for transformers, circuit breakers, CT/PT, relay protection, cable and electric power systems to test and calibration equipment.
Sansion has obtained ISO 9001 quality certificate and all of our products are in conformity with the international standards.
With superior quality, reasonable price and perfect after-sales service, we are aiming to expand the markets in all countries of the world. We look forward to working with you.
FAQ:
1.Q:Are you Manufacturer of trading company?
A: We are manufacturer of more than 20 years in power testing product.
2..Q:How can I pay?
A:Dear customer, we accept many payment term, such as T/T, Western Union…
3.Q:What is your terms of delivery?
A:We accept EXW,FOB, CFR, CIF, ect. You can choose the one which is the most convenient and cost effective for you.
4.Q:Could you please tell me the Warranty Period of your product?
.A:Warranty period is one year. Engineers available to service the equipment.
5.Q:What should I do if I do not know how to use?
A:Dear customer, please do not worry, manual user will be sent together, you can also contact us with more technological support.
