portable ultrasonic flaw detector ultrasonic weld test equipment testing
- 500 Set / Sets per Month
- Jinan
- T/T Credit Card
You May Like
Product Details
| Brand Name | PTE | Place of Origin | Shandong, China | |
| Model Number | PTE-YFD200 | Power | Electronic | |
Product Description
YFD200 Digital Portable NDT Ultrasonic Flaw Detector
Application
YFD200 digital portable ultrasonic flaw detector is used for electronic power, petrochemical, boilers and pressure vessel, pressure pipe, steel structure, military, aviation, railway transportation, car, machinery, etc. It is the necessary instruments in nondestructive testing industry.
Low noise scan, good performance. All painted metal case, beautiful, solid and the anti-interference function. Strong powerful PC Software can export Excel format testing report.
Features
· Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB)
· Automated switch three staff gauge ((Depth d,level p,distance s)
· Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity
· Convenient to make and use DAC and AVG to evaluate the echo, the curve can be modified and compensated
· Ten independence setup, any criterion can be input freely, we can work in the scene without test block
· Big memory of 300 A graph and 30000 thickness value.
· Automated gain and gain scan;
· Automated make video of test process and play;
· Peak Hold and Peak Memory
· B scan;
·Powerful pc software and reports can be export to excel;
·The embedded software can be online updated
·Li battery, continuous working time up to 10 hours;
·Solid metal housing
Technical Specification
Title | Parameter | Title | Parameter |
Measuring range(mm) | 0 ~ 10000 | Measurement mode | single,dual, THRU |
Vertical linearity error | ≤2.5% | Reject | 0-80% |
Horizontal linearity error | ≤0.1% | Pulse shift(μs) | -20 ~ +3400 |
Sensitivity margin | ≥62dB | Zero | (μs) 0.0 ~ 99.99 |
Dynamic scope | ≥34dB | Port type | C9 |
Resolution | ≥36dB | Operating temperature | -20~50 |
Frequency range(MHz) | 0.5 ~ 20 | H×W×D(mm) | 240×150×50 |
Gain(dB) | 0 ~ 110 | Weight(kg) | 1.6 |
Velocity | 1000 ~ 15000 | -- | -- |
Package:
