Analog Display Hydraulic tensile/compression Universal Testing Machine WE-50C
- 35 Set / Sets per Month
- Qingdao
- T/T Credit Card
- Model WAW-1000C Computer Controlled Electro-hydraulic Servo Universal Testing Machine
- Hydraulic Universal Testing machine WAW-1000E
- WAW-C Computerized Servo Hydraulic Universal Tester / Universal Testing Machine Manufacture
- Computer Control Three Closed-loop Hydraulic Servo Universal Tensile Mechanical Equipment
- WAW-1000Y Low Carbon Steel Usage Computer Control Hydraulic Servo Universal Tensile Tester
- WAW-EI Series universal testing machine specification
Product Details
Brand Name: | PTE | Place of Origin: | Shandong, China | Model Number: | WE-50C |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
WE-C series Low Price Hydraulic Analog universal Testing Machine
This machine is mainly used in test of tensile, compression, bending of metal materials as well as wood,cement and concrete, etc non-metallic materials. With hydraulic load, it is convenient in operation, stable in performance and safe and reliable. It adopts oil hydraulic power to drive the piston in the oil cylinder to provide loading force on test samples. It adopts analog dial dynamometer to display the test results. The test force is
displayed on the dial plate and the liner ruler will indicate the stroke. This machine equips with a mechanical plotter, which can draw the deformed curves of the materials roughly. It is necessary inspect device in the filed of steel and iron factory, the laboratories of scientific research institutes, infrastructure construction organs,machinery plants and education for research and teaching , etc.
Features:
Rigid 2-column& 2-lead screw type with compact design
Dual workspace design: Upper for tension, lower for compression or bending tests, etc
Movable lower crosshead adjust test space rapidly
Load measuring piston to measure the test load
Open type hydraulic wedge grips for easy change of inserts and specimen loading
Cylinder mounted at the bottom of the machine
Test fast and simple operation
Packaging Detail:
1. Inner package: dust-proof plastic bag
2. Outer package: standard export wooden case with pallet
3. Special packages: according to buyer's requirements
4. The packages suitable for international transport by sea, by air or any other delivery methods
--------------------------------------------------------------------------------------------------------------------------------------------------------
1. Pre-service
--24 Hours online service for your consult.
--Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
Our company is one of the top-ranking manufacturers and suppliers of test machines worldwide. With many years of experience in this filed, we can supply standard and customized solutions for many test, measurement and quality control tasks required in the world of modern materials test.
For more product:
Compressive strength testing machine for concrete
Model | YES-1000 |
Load display accuracy | ±1% |
Distance between upper | 320mm |
Diameter of lower platen | 300 mm |
Piston stroke | 30mm |
Pump nominated pressure | 40MPa |
-------------------------------------------------------------------------------------------------------------------------------------------------------
Strength testing machine (single column):
Model | WDW-E1,E2, E3, E5, E10, E20, E30, E50, E100 |
Max. Load | 1kN,2kN,3kN,5kN,10kN,20kN |
Deformation accuracy | ≤±0.5% |
Load speed | 0.005-500mm/min |
Total crosshead travel (mm) | 1075 |
Spacing of grip to grip(mm) | 750 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
PLG 300C PC Control High Frequency Fatigue Testing Machine
Model | PLG-10C PLG-20C PLG-50C PLG-100C PLG-200C PLG-300C |
Mean load max(kN) | ±10 .... |
Load step | 1,2,5 |
Accuracy of static load | ≤±1% |
Range of frequency(Hz) | 60~300HZ |
Power | 380V, 3phs, |
-------------------------------------------------------------------------------------------------------------------------
WAW Computer Control Servo Hydraulic Universal Testing Machine
Model | WAW-300E WAW-600E WAW-1000E WAW-2000E |
Max. Testing Load (kN) | 300 .... |
Load Accuracy | ≤±1% from 2% to 100% of full scale |
Strain accuracy | ≤±0.5% |
Load frame Type | 4-column and 2-screw structure |
Max. tensile space (Including piston | 690 |
-------------------------------------------------------------------------------------------------------------------------------------------------------
Our product range:
1. Electromechanical Universal Testing Machine
2. Hydraulic universal testing machine
3. Spring testing machine
4. Fatigue testing machine
5. Creep and rupture testing machine
6. Horizontal tensile testing machine
7. Torsion testing machine
8. Cold bending testing machine
9. Cupping testing machine
10. Impact testing machine (Nist)
11. DWTT drop weight testing machine.
12. Compression testing machine
13. Friction and wear testing machine
