Home > Furniture > Lab Furniture > Lab Bench > Lab Work Top Ductless Medicine Storage Cabinet With Filter Lab Ductless Reagent Storage Cabinet

Lab Work Top Ductless Medicine Storage Cabinet With Filter Lab Ductless Reagent Storage Cabinet

US$ 300 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Hopui
Place of Origin:
Guangdong, China
Model Number:
Lab clean gas medicine cabinet
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Hopui
Place of Origin Guangdong, China
Model Number Lab clean gas medicine cabinet
Product Description

1. Metal parts: main material ≥1.2mm galvanized steel plate, epoxy resin electrostatic spraying, coated with durable anti-chemical lead-free coating, maintaining high finish and minimizing the effects of corrosion and moisture.

2, door panel: the main material ≥ 6mm acrylic plate, excellent weather resistance, excellent chemical resistance, not easy to aging, colorless and transparent, transparent body, visual comfort, beautiful and generous.

3. Laminate: Main material ≥1.2mm galvanized steel plate, anti-corrosion coating, acid and alkali resistant, height adjustable.

4, anti-acid and alkali leakage liquid drawer: polypropylene PP liner, corrosion resistance, to prevent reagent bottles from breaking liquid leakage.

5, seven-inch LCD touch screen display, high-definition display resolution 1024 * 600, perfect vision system.

6, real-time temperature and humidity environment monitoring system, display real-time temperature and humidity, set alarm parameters to ensure product safety.

7, fan monitoring: fan system failure alarm, online adjustable fan speed to ensure the storage requirements of different chemicals.

8. Filter saturation alarm system: The filter sets the saturation alarm value. If it exceeds the range, it will alarm. Corresponding to the VOC concentration level, the filter needs to be replaced when the alarm and concentration level are at the same time.

9, the United States imported PSC fan, 24 volts, stable performance, ultra-quiet, no spark static.

10, high-efficiency filtration system, according to the size of the particles to choose the distribution, in accordance with ASTM standards, effective for acid gases and organic gases, strong adsorption capacity, for particle filters, the use of high-efficiency HEPA filter, for particles larger than 0.3um, filtration efficiency 99.995%.

11. Scan the machine QR code, and the WeChat client can view the running status of the device in real time and change the running data of the device.

Detailed Images
Feature

1. There is no need to install pipeline engineering, the installation is convenient, the exhaust gas is not discharged, and the new environmental protection.

2. The top is equipped with a filter module system according to the chemical category to meet a variety of different types of chemical storage.

3. Advanced modular filtration technology, completely adsorbing harmful gases, particulate dust and other substances generated by filtration experiments.

4. No need to consume air conditioning energy, saving energy efficiently.

5. Easy to move, close to the store, easy to access, improve work efficiency.

6. Online monitoring of indoor environmental conditions and filter usage status, according to the laboratory environment level, the user can set the safety reminder concentration.

Working principle

1, the fan
The fan at the top of the cabinet draws air from the laboratory into the interior of the cabinet to create a negative pressure.

2, gas filtration
The harmful gases volatilized by the reagents stored in the cabinet enter the filter module through the fan, and the toxic and harmful gas molecules are intercepted and filtered by the filter, and the clean gas is returned to the room.

3, high-quality air purification function filtered clean air returned to the room, will not endanger the health of personnel.

4. Purify laboratory air
Purify the air in the laboratory for 24 hours and improve the air quality of the laboratory (it is recommended to keep the medicine cabinet open for 24 hours)

specifications Model
Specification model
BC-G819
parameter
External dimensions: 800*510*2070-2360mm

Internal dimensions: 708*450*1750mm

Molecular filter size: 370*395*50mm

Initial effect filter size: 740*396*21mm

Laminate: 8 blocks

Laminate load-bearing: >70kg/m2

Air handling capacity: 220m3/h

Cabinet volume: 0.55 m3

Storage capacity: 160 bottles (500ml)

Volume: 50dBA

Voltage: 220V/50Hz

Power: 35W

Current: 0.25A
Configuration
Molecular filter: 4 groups

Primary filter: 1

Fan: 1

Laminate: 8 blocks

Display: seven inches LCD

touch screen

Control system: 1 set

Filter saturation alarm system: 1 set

Temperature and humidity alarm system: 1 set

Power cord: 1

Lock: double lock (flat lock + padlock)
Optional
Transparent door

Light shelter

Acid-base box

Optional filter model:

SFGL OG: Organic Filter

SFGL AG: Inorganic filter

SFGL AM: Ammonia filter

SFGL FO: formaldehyde filter

HEPA H14: High efficiency HEPA filter

Note:

First purchase with all configurations;

The filter model is configured according to the type of chemical stored by the user.
Our Company

Guangzhou Ho Pui Laboratory Equipment Co., Ltd.

Hopui is one of the most professional integration engineering company in modern laboratory research, supplies all process including laboratory design, laboratory equipment production, laboratory furniture installation and after- sale service. We have high-quality production lines, and use the best lab furniture materials and a modern standard from the USA and Europe. We can make the whole lab projects match your laboratories with our perfect design.

Factory

We have our own factory, all product are manufactured by our own equipments, we have a series of production equipments, so our products' quality is guaranteed.
Our company has ISO9001, ISO14001 and CE Certifications, we guarantee to provide customers with high quality products.
