The Brief introduction of PP melt-blown Filter:
PP melt-blown Filter is composed of polypropylene superfine fiber which melted and entangled at high temperatures. The fiber without any chemical adhesives forms three-dimensional micro porous structure which integrates the surface, the deep and the coarse filter together. Because the fiber and density in the diameter direction of the filter forms deep filtering structure with high filtration precision, high pollutant assimilative capacity, small pressure difference, dense inside and sparse outside gradient aperture structure. It has strong pollutant assimilative capacity, and can effectively remove the impurities such as suspended solids in the flow of fluid, particles, rust, etc. it also have a good filtering performance and long service life.
The Application fields of PP Melt-blown filter:
a. used in drinking water filtration, RO antiosmosis filtration
b. used in the acid and alkali liquid filtration in industrial chemistry
c. The filtration of industrial water and plating solution
d. The filtration of imaging solution and ink
e. The pre-filtration of sterile water and ultra-pure water
f. The filtration of chemical materials and organic solvent
The Production Features of PP Melt-blown filter:
a. The surface with deep hole groove structure can scatter the direction of flow and reduce the flow resistance
b. Progressive density structure can increase the carrying capacity of the pollutant
c. Reinforce the surface fiber structure and reduce the depilation possibility
d. Be made of PP superfine fiber which have high filtration precision
e. 100% pure PP can ensure high corrosion resistance
f. shape in hot melt way without any chemical adhesive
The Technical specifications of PP Melt-blown filter:
Filter Size：
External diameter：63mm，110mm
Inner diameter：28mm，30mm
Length：9.75" 、9.87" 、10" 、20" 、30" 、40" 、50" 、60"
Material：
Filter material：polypropylene （PP）
End cover：polypropylene
Center pole: polypropylene
Spacer/ seal ring: silicon rubber, Ethylene Propylene Rubber (EPR), nitrile rubber buna (NBR), FPM
Filter element performance:
Filtering accuracy: 1μm、3μm、5μm、10μm、25μm、50μm、75μm、100μm、150μm
The highest operating temperature: 80℃
The maximum PSID (Pounds per Square Inch Differential): 2.0Bar，21℃
