plastic nose wire making machine
Main parameter:
Screw diameter 55mm
Voltage:220v or 380v
Main motor power:5.5kw
Capacity :20kg/hour
This line including the extruder, water tank,dragger,rewinder.
Plastic nose bar making machine component:
extruder
Screw Diameter |
65mm |
Screw Ratio(L/D) |
25:1 |
Output |
20kg/h |
Total Power |
10KW |
Weight Of Machine |
815kg |
Dimension(mm) |
2600x950x1250mm |
water tank
Dimension(mm) |
1350x320x1000mm |
Weight Of Machine |
150kg |
Dragger
Front drag motor power |
1.5kw |
Back drag motor power |
3kw |
Weight Of Machine |
180kg |
Dimension(mm) |
1100x650x1000mm |
Screw Speed |
10-80m/min |
Rewinder
Rewinder Diameter |
350mm |
Speed |
120m/min |
Power of Main Motor |
4KW |
Weight Of Machine |
200kg |
Dimension(mm) |
1200x900x1050mm |
Plastic plus metal wire nose bar making machine component::
extruder
Screw Diameter |
65mm |
Screw Ratio(L/D) |
25:1 |
Output |
20kg/h |
Total Power |
10KW |
Weight Of Machine |
815kg |
Dimension(mm) |
2600x950x1250mm |
water tank
Dimension(mm) |
3000x350x1050mm |
Weight Of Machine |
150kg |
Dragger
Front drag motor power |
1.5kw |
Back drag motor power |
3kw |
Weight Of Machine |
180kg |
Dimension(mm) |
1100x650x1000mm |
Speed |
10-110m/min |
Rewinder
Rewinder Diameter |
350mm |
Speed |
150m/min |
Power of Main Motor |
4KW |
Weight Of Machine |
200kg |
Dimension(mm) |
1200x900x1050mm |
Feeding wire rack:
Dimension(mm) |
600x500x600mm |
Weight Of Machine |
150kg |
Moving wire rack:
Dimension(mm) |
500x500x1100mm |
Weight Of Machine |
100kg |
