Home > Products > Drinking straw making machine > HAS VIDEO Machine To Make Lollipop Stick With Notch Knife and Gathering Device
HAS VIDEO Machine To Make Lollipop Stick With Notch Knife and Gathering Device
- NINGBO PORT
- T/T Credit Card
You May Like
Product Details
| Brand Name | XIAOHAI | Place of Origin | Zhejiang, China | |
| Model Number | JH01 | Certification | CE ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 800KG | |
| Dimension(L*W*H) | 7100*1300*1500mm | Voltage | 220V/380V/415V | |
| Application | Film | Condition | New | |
| Automatic Grade | Auto | Plastic Processed | PP | |
| Screw Design | Single-screw |
wooden box
Product Description
machine to make lollipop stick
lollipop sticks output: 40,000-50,000pcs/h
Material: PP,PE
Cutting edge: 90°/90°,90°/45°,90°/60°,45°/45°,60°/60°
Colour:Single
General description
Material:PP,PE
Extrusion output:
Extruder Model | Extrusion outputt | Remark |
50×28 | 15kg/h( sticks) | PP,PE |
Extruder screw diameter:50mm
1. 1 set of JH01-150 Single-screw extruder
General description | Main electric elements
| Frequency inverter: Delta Contactor: Delixi Temperature controller: Huibang Motor: made in China |
Output(max) | 30kg/h | |
Connect type of extruder and mould | Bolt connection | |
Advantages | Main parts adopt top-rank brand Strict real time quality control | |
Screw | Diameter(mm) | 50mm(1 set) |
L/D | 28/1 | |
Material | 38CrMoAlA, Nitrogen treated | |
Heating | Heating roller | |
Heating segments | 3zone 3 | |
Heating power | 8kw | |
Barrel | Barrel type | With feeding groove |
Cooling | Cooling by water temperature control accuracy:±1°C | |
Cooling segment | 3 segments | |
Material | 38CrMoAlA, Nitrogen treated | |
Drive and Transmission system | Main motor power(KW) | 7.5kw |
Speed adjusting mode of main motor | Variable frequency conversion | |
Extruder | Figure dimension(mm) | 2100*1300*1500 |
Weight(kg) | 1200 |
2. 2 set of mould for lollipop sticks
Item | Description | Unit |
|
1 | Diameter range(OD) | mm | 1-6mm |
2 | Wall thickness | / | 0.2-1mm |
3 | Material of the mould body | / | Steel 45# 45,harden treated and polished |
4 | Material of inner mould parts | / | 40Cr |
3. 1 set of cooling tank
NO | Description | Unit | Remark |
| |||
1 | Length of the tank | mm | 5000 |
2 | Material of water tank | / | stainless steel:SUS304 |
3 | Cooling Mode | / | Spray-pouring cooling |
5 | Pouring areas | / | 3in4out |
6 | Figure dimension | mm | 5000*700*1200 |
7 | Weight | kg | 200 |
Remarks:
1).Price term: FOB Ningbo.
2).Terms of payment:30% deposit and pay the balance before shipment by TT. (L/C also ok)
3).Delivery time: Within 30 days after receiving 30% deposit.
4).Packaging: Seaworthy packing(wooden case).
5).Guarantee:1 year
Company Profile
We are a Big Group specializing in making all kinds of printing and plastic machines, such as plastic bag whole line machines (film blowing machines, flexo and gravure printing machines, lamination machines, all kinds of bag making machines), disposable glove making machines, plastic cup and paper cup making whole line machines, drink straw making whole line machines, label whole line making machines, and paper cutting whole line machines.
