High Precision Plasma Corona Treatment For Processing Plastic, Rubber, Glass, Ceramics, Metals
US$ 3,500 - 3,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
XIAOHAI
Place of Origin:
Guangdong, China
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support, Video technical support
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HLD-801 Computer Controller for Bag Making MachineUS$ 400 - 460MOQ: 1 Set -
Medical Trash Waste Packaging Bag Making MachineUS$ 5,000 - 10,000MOQ: 1 Set
-
HAS VIDEO HDPE LDPE Extruders for Plastic FilmUS$ 1,000 - 10,000MOQ: 1 Set
-
Kesai Original Printing Color-con Mark Sensor for Printing MachineUS$ 800 - 1,000MOQ: 1 Piece
-
All Kinds of High Precision Pneumatic Handle Hole Puncher Device for Hand BagsUS$ 400 - 400MOQ: 1 Set
Brand Name
XIAOHAI
Place of Origin
Guangdong, China
Product Description
Plasma surface treatment machine
Use / application area
PP material, PE material, solve the problem of printing, bonding, and weakness, glass, ceramic, metal, plastic, etc., silica gel, and other materials surface cleaning treatment, the adhesion is obviously improved after treatment.
In the liquid crystal panel industry, the connection between the display screen and the flexible film circuit in the production process of mobile phone, touch screen, notebook computer display and other products has been subjected to hot pressing method, that is, the flexible film circuit is directly bonded by heating and pressing. On the glass with LCD wiring points, this process requires the glass plane to be clean, but the glass surface is easily contaminated during actual production, storage and transportation. If it is not cleaned, fingerprints or dust will inevitably appear. . The short circuit caused by these surface impurity particles may cause the display segment of the LCD to malfunction for a period of time, usually as a display missing or a disorder in the display. In addition to this, the poor adhesion of the thin film circuit and the glass due to the low surface tension may cause malfunction. The traditional way to solve this problem is to use a cotton swab and detergent to manually clean the glass of the LCD, but this treatment will result in an average scrap rate of up to 12%. The plasma glass technology is used to clean the LCD glass, removing the impurity particles, improving the surface energy of the material, and increasing the yield of the product by an order of magnitude. At the same time, since the jet low temperature plasma is electrically neutral, the protective film, the ITO film layer and the polarizing filter are not damaged during processing. This process can be carried out "online" and requires no solvent and is therefore more environmentally friendly.
technical parameter
1. Input voltage: 220Vac (±20%)
2. Input voltage fluctuation range: ±5V
3. Input power: 500-600VA
4. Input current: 2.4A-3.1A
5. Processing width: 40-50mm
6. Air source pressure: 0.10Mpa~0.30MPa (1.0Kg~3.0Kg)
7. Machine size: length*width*height,:560mm * 253mm * 460mm
8. Nozzle size: MAX 280mm*79mm*79mm
9. Weight: 35Kg
1. Input voltage: 220Vac (±20%)
2. Input voltage fluctuation range: ±5V
3. Input power: 500-600VA
4. Input current: 2.4A-3.1A
5. Processing width: 40-50mm
6. Air source pressure: 0.10Mpa~0.30MPa (1.0Kg~3.0Kg)
7. Machine size: length*width*height,:560mm * 253mm * 460mm
8. Nozzle size: MAX 280mm*79mm*79mm
9. Weight: 35Kg
