Hsuperior Performance Igh Precision Low Price Total Station
| Electronic Total Station DTM152M | Electronic Total Station DTM152M | |
| Telescope | ||
| Image | Erect | |
| Magnification | 30× | |
| Effective aperture | 48mm | |
| Resolving power | 3.75″ | |
| Minimum focus | 1m | |
| Stadia ratio | 100 | |
| Sight distance precision | ≤0.4%D | |
| Tube length | 165mm | |
| Angle Measurement | ||
| Measuring method | photoelectric detection by incremental encoder | |
| Diameter of circle (vertical, horizontal) | 79mm | |
| Minimum reading | 1″,5″,10″Selectable | |
| Measuring unit | 360°/400gon/6400mil Selectable | |
| Vertical angle0° | Zenith0°/Horizontal0°Selectable | |
| Accuracy | 2″ | |
| Distance Measurement | ||
| Single prism(under fair weather condition) | 3km | |
| Three prism(under fair weather condition) | 5km | |
| Display | Max: | 999999.999m |
| Min: | 1mm | |
| Unit | m/ft Selectable | |
| Accuracy | ±(3mm+2ppm·D) | |
| Measuring time | Fine single shot: | 3S |
| Tracking: | 0.8 S | |
| Meteorological Correction | Manual input, Auto correction | |
| Reflection prism correction | Reflection prism correction | |
| Vial | ||
| Plate vial | 20″/2mm | |
| Circular vial | 8′/2mm | |
| Vertical Compensator | ||
| System | Liquid-electric detection | |
| Compensation range | ±3′ | |
| Resolving power | 1″ | |
| Optical Plummet | ||
| Image | Erect | |
| Magnification | 3× | |
| Focusing range | 0.3m~∞ | |
| Field of view | 5° | |
| Display | ||
| Type | LCD,Four lines,digital | |
| Data Communication | ||
| Port | RS-232C,USB | |
| On-board Battery | ||
| Power resource | Rechargeable Ni-H battery | |
| Voltage | DC7.2V | |
| Continuous operation time | BDC 3000mAh | |
| Angle measurement: 20 hours | ||
| Distance measurement: 8 hours | ||
| Operation Environment | ||
| Operating temperature | -20°~+45℃ | |
| Size & weight | ||
| Dimension | 180mm×175mm×355mm | |
| Weight | 6.5kg | |
