Description :
Wheel tracking machine
It can be used as water immersion test.
It can test 2 specimens at the same time.
Automatic temperature control, automatic generation and save the test results, Convenient call history data, output test result.
Point to point data collection: the position of the upper and lower machine control system to ensure the deformation repetitive gathering space.
High resolution data acquisition, high speed.
Wide temperature range, high precision, good stability,PWM modulation method is adopted to improve the temperature PID control, to ensure that the temperature without overshoot.
Using absolute temperature sensor to collect temperature, test without temperature drift for a long time (to eliminate the general thermocouple temperature sensor working temperature drift for a long time) on the test data.
Air circulation in the oven, high temperature control precision.
Displacement sensor with high precision, under the big range accuracy is less than + / - 0.05 mm.
Equipped with constant temperature box integration structure, easy to move.
Smooth operation, no noisy.
Available computer with touch screen independently control (optional).
Can preheat six test at the same time.
Small volume, covers an area of only 1.52 m × 1.1 m.
This machine is equipped with one piece personal computer with Win-8 English operating system and one piece printer.
Specifiction:
Model HYCZ-1
Heating Power: 3000W
Driving Motor Power: 750W
Electrical supply: 380V
Specimen size: 300x300x50mm or other require dimension
Working Method: crank connecting rod driven test wheel movement
Rubber wheel hardness: 84±4 international standard
Test wheel moving distance: 230mm±10mm
Load cycles: 21±1 cycles/min,or 26.5±1 cycles/min
Loading device: the contact pressure is 0.7±0.05Mpa when the temperature is 60oC, total loading is around 78kg and adjustable
Deformation measurement precision:0.3%
Temperature control precision: 0.5oC
Working temperature: 0~80oC humidity90%, haven't corrosive and fl ammable gas
Weight: 500Kg
