Brand Name C-TECH
Place of Origin Hebei, China
Model Number A series
Power Electronic

Marshall stability tester

Used to determine the stability of the bituminous mix materials and capability of resistance against plastic deformation and flow value of the materials.

Equipped with an LCD Data Acquisition System control the test and display the results in a very easy and simple way and, a memory to store up to 1000 test results to recall them in the future.

Has a capacity of 50 kN and a loading rate of 2”/minute (50.8 mm/min).

Fully automatic and to stop the test by itself when finishes and return to its initial position.

Equipped with RS 232 port for computer connection and thermal printer (which should be ordered separately) to report the results quickly and directly from the machine.

Supplied with load cell that has a capacity of 50 kN and flow-meter

50kn digital asphalt Marshall stability test apparatus to determin bitumen mixer



Specifications:

Model No.
LD-5
Max Capacity:50kN
Test Rate:50.8mm/min
Cross Head Travel:70mm
Displacement Probe Travel:15mm
Verticial Clearance:300mm
Horizontal Clearance:270mm
Dimension(mm):590(L)*310(W)*750(H)
Approx. Weight:90kgs
Power:220V, 50/60Hz, 1 ph, 0.5Hp,2.3A
