Soil Dynamic Penetrometer DPL DPM With Pneumatic Drive
US$ 3,000 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
TIANPENG
Place of Origin:
Hebei, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Granular Soil Relative Density ApparatusUS$ 1,800 - 2,500MOQ: 1 Set -
Steel CBR Test Mould and AccessoriesUS$ 5 - 50MOQ: 1 Set
-
Soil Pneumatic Driven DCP Dynamic Cone PenetrometerUS$ 3,000 - 3,000MOQ: 1 Set
-
Pocket Soil Penetrometer Mini KitUS$ 35 - 60MOQ: 1 Set
-
FVST Pocket Shear Vane Device SetUS$ 160 - 160MOQ: 1 Set
Brand Name
TIANPENG
Place of Origin
Hebei, China
Soil Dynamic penetrometer DPL DPM with pneumatic drive
Dynamic penetrometer light DPL with pneumatic drive is most commonly used device for soil compaction testing up to 10 meters depth.
Compact and very light compressor (only 15,6 kg) with a Honda engine is mounted on solid frame. Construction of the device
allows comfortable usage, all accessories are mounted on a special holder and therefore it is very easy to transport on the
site of survey. Number of strokes can be adjusted manually. The ball valve can stop the work of the penetrometer at any time
without the need of shutting the compressor down. The penetrometer can be supplied with standard extension rods
(diameter 22 mm, threaded nipple M16) and survey cone.
Specifications
COMPRISES:
16-T0012/P1 portable compressor set with Briggs &
Stratton gasoline engine and integrated air
cooling. Fixed 10 kg and 20 kg additional
drop weights.
16-T0012/P2 Sounding tube (22 x 1000 mm) with depth
indication every 100 mm 12pcs
16-T0012/P3 Threaded nipple M16 for sounding rod (22
mm) 12pcs
16-T0012/P4 Open ended spanner 19 mm – Heavy duty
design for 22 mm sounding tubes
16-T0012/P5 Allen key M8 for threaded nipples M16
16-T0012/P6 Manual rod puller with football and lever
16-T0012/P7 Conical sounding tip of tempered steel - 5
cm², M16 connection 2pcs
16-T0012/P8 Conical sounding tip of tempered steel - 10
cm², M16 connection 2pcs
16-T0012/P9 Conical sounding tip - 10 cm² - single use
type 20pcs
16-T0012/P1 portable compressor set with Briggs &
Stratton gasoline engine and integrated air
cooling. Fixed 10 kg and 20 kg additional
drop weights.
16-T0012/P2 Sounding tube (22 x 1000 mm) with depth
indication every 100 mm 12pcs
16-T0012/P3 Threaded nipple M16 for sounding rod (22
mm) 12pcs
16-T0012/P4 Open ended spanner 19 mm – Heavy duty
design for 22 mm sounding tubes
16-T0012/P5 Allen key M8 for threaded nipples M16
16-T0012/P6 Manual rod puller with football and lever
16-T0012/P7 Conical sounding tip of tempered steel - 5
cm², M16 connection 2pcs
16-T0012/P8 Conical sounding tip of tempered steel - 10
cm², M16 connection 2pcs
16-T0012/P9 Conical sounding tip - 10 cm² - single use
type 20pcs
