150Kn Soil Electric Hydraulic Universal Extruder and Ejector
US$ 550 - 650
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
C-TECH
Place of Origin:
Hebei, China
Model Number:
ct
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Soil Testing Equipment 0-300kn Soil Plate Bearing Load Test ApparatusUS$ 500 - 500MOQ: 1 Set -
Soil Rammer Soil Electric Multifunctional CompractorUS$ 950 - 1,000MOQ: 1 Set
-
Casagrande Apparatus Casagrande Method Manual Liquid Limit Test SetUS$ 300 - 700MOQ: 1 Set
-
Cylinder CBR Test Mould With Base and Collar for Soil TestingUS$ 40 - 60MOQ: 10 Pieces
-
CBR Plated Steel Proctor Mould and Rammer For Soil CompactionUS$ 30 - 60MOQ: 10 Pieces
Brand Name
C-TECH
Place of Origin
Hebei, China
Model Number
ct
Power
Hydraulic
Description:
Electric universal extruder
The ejector is used for ejecting the specimen made of bituminous mix material and the material stabilized with inorganic binders etc. Hydraulic Universal Extruder can quickly eject the specimen from the mold and easy to operate.
Specifiction:
Model CT
| Mold dimensions | |
| Soil specimen | Dia. 102 x 116 mm/Dia. 152 x 116 |
| Bituminous mix material specimen | Dia. 101.6 x 87 mm |
|
Material stability with inorganic binders |
Dia. 50mm × 50mm Dia. 100mm × 100mm Dia. 150mm × 150mm |
| Maximum axialcapacity | 150 KN |
| Maximum travel | 250mm |
| Speed forward/reverse | 170mm/min. |
| Power supply | 380V 50Hz |
| Input power | 1100 W |
