Description:
Multifunctional compactor
soil Electric Multifunctional Compractor suitable for the foundation engineering construction such as water conservancy dam, traffic, railway, airport and building etc. With standard compaction method to determine the relationship between density and water ratio, then confi rm the dry density and moisture content of soil.
soil Electric Multifunctional Compractor could satisfy the specimen preparation requirements of CBR tests and resilience modulus tests.
soil Electric Multifunctional Compractor could provide sand module and spodosol module of dia.152 and dia. 100. It could perform light compaction and heavy compaction. With perfect designation, it has lots of specialties such as digital display, auto number and auto circulation etc.
Specifiction:
Model EDC-1
| Heavy-duty compacting test | hammer weight 4.5kg drop height 450mm |
| Light-duty compacting test | hammer weight 2.5kg drop height 300mm |
| Specimen cylinder dia. | dia. 100, dia. 152 mm |
| Hammer head dia. | dia. 50 mm |
| Compacting number | 30 times/min |
| Power | 370 W, 380 V, 1400 r/min |
| Dimension | 650×400×1320 mm |
| Weight | 130 Kg |
