60KN Bench Unsaturated Soil Triaxial Apparatus to Determine the Resisting Shear Strength
US$ 8,800 - 8,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
C-TECH
Place of Origin:
Hebei, China
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RELATIVE DENSITY APPARATUS For Cohesionless Soil TestUS$ 1,700 - 2,100MOQ: 1 Set -
Large Capacity Sample SplitterUS$ 500 - 650MOQ: 1 Set
-
Low Pressure Triplex Consolidation Test MachineUS$ 600 - 750MOQ: 1 Set
-
Mid and Low Pressure Soil Triplex Consolidation Test ApparatusUS$ 880 - 880MOQ: 1 Set
-
China Soil Manual Dynamic Cone Penetrometer DCP for SaleUS$ 380 - 600MOQ: 1 Set
Brand Name
C-TECH
Place of Origin
Hebei, China
Bench Unsaturated soil triaxial apparatus
Specifications:
TheApparatus is used to determine the resisting shear strength of the soil specimen with maximum
confining pressure of 2.0MPa and specimen dimension is of Φ61.8x125mm,Φ101x200mm. The apparatus can
perform unconsolidated-undrained shear test (UU),consolidated-undrained shear test (CU), and
consolidated-drained (CD) shear test. It consists of frame, test control device,pressure chamber and specimen
tools etc.
Technical parameters
| Specimen | 61.8mm *125mm |
| Capacity | 60kn |
| Confining pressure | 0~600kPa Digital control and display |
| Sear speed | 0.0016~4mm/min |
| Back pressure | 0~500kPa Digital control and display |
| Axial force | F=0~6kN |
| Pore pressure | (water)-30kPa~600kPa, (air)00~600kPa |
| Clay inlet value force | S=300kPa,500kPa |
| Volume deformation | V=0~50cm, minimum resolution:0.1ml |
