HT-225W Digital Concrete Sclerometer

HT-225W Digital Concrete Sclerometer photo-1
HT-225W Digital Concrete Sclerometer photo-2
HT-225W Digital Concrete Sclerometer photo-3
US$ 450 - 450 MOQ: 2 Sets
Key Specifications
Get Latest Price
Brand Name:
C-TECH
Place of Origin:
China
Model Number:
HT-225w
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name C-TECH
Place of Origin China
Model Number HT-225w

Digital Concrete test hammer

This new and advanced model of digital concrete hammer microprocessor operated consists of the standard unit similar to the model HT225-A but equipped with an electronic transducer which converts the rebound of the hammer into an electric signal and displays it in the selected stress unit. The digital hammer, which is battery operated, can be easily connected to a PC or serial printer via the RS 232 port. A large permanent memory can store up to 48000 results. Supplied complete with battery charger and serial cable.

HT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometer



Specifications:

Measuring strength ranges10-60 Mpa
Impact energy2.207 Nm
Strike hammer stroke75 mm


The consistency of the sample displayed values:±0.5(difference value between digital sampling output value and the pointer readings)
Measurement range from 10 to 70N/mm2
The rebound values calibrated on steel anvil:80±2
Display: 16-bit true color, 176×220 resolution, 5 grades backlight adjustment
Power: 16-T0012/A , charging powe r a d a p t e r 5 V / 2 A. Maximum backlight, turn off speech cases, it can be continuous work 13 hours.

Power consumption appox: 100 mA (Voice off)
Maximum backlight situation

Communication interface: USB2.0 full-speed
Gross weight approx: 4.5 Kg

HT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometerHT-225W Digital concrete sclerometer
