Chloride is an important factor in inducing steel corrosion. In order to avoid premature corrosion of steel, concrete materials control chloride ion content of it very strict.
Rapid chloride tester
Features:
• Handheld Instruments have light weight and small size which easy for users to take with and on-site inspection. Printer to print data in any time is available for select. This run independently even without computer control. Bench Instruments have large-size LCD panel to indicate data and an embedded printer to print data easily.
• Unique anti- ion interference agent can prevent it from cyanide , ammonia oxidation effect of ions as well as manganese and lead made the combined effect of metal ions.
• Unique PC analysis software, which has a national computer software copyright.
• Unique linear regression coeffi cient calculation program make self-diagnostic instrument status available.
• Embedded standard formula can directly calculate concrete mixture chloride ion content.
• Direct output the unit results in a molar concentration and percentage.
• Mass storage of 100 data storage, continuous data record, safe and reliable.
• Software for testing and report preparation.
• Testing up to 6,9,12 cells simultaneously
• Documentation of each test result, easy to assemble, simple to maintain, watertight cells. Model NJCL-H’s unique feature
• Show calibration curves and color display, which can be saved and read.
• Directly to the built-in temperature compensation formula makes test results more intuitive.
| NJCL-H | NJCL-L | NJCL-B | NJCL-C |
| Measureme n t accuracy:<10% |
Measurement accuracy:<10%(Result<5%) | Measurement accuracy:<10% | |
| Collect time: ≤3min | Collect time: 30s | Collect time: ≤3min | |
| Weight:2.5kg | Weight:0.4kg | ||
| Power: AC 220V | |||
| Power: DC 7.2V | Power: DC 3.6V | ||
| Temperature error:1℃ |
Power supply:1) DC 3.6V adapter 2)Lithium battery |
||
| Printer power: DC 5V | Battery life: 12 months(8h/day) | ||
| Work temperature: 0 ℃ ~ 40 ℃ | |||
| PC Communication parameter:2400 baud rate | |||
| Range:0.001%-30.000%(Cl¯),10¯5-10¯1(mol • L¯1) | |||
