- Main products: SGP interlayer
0.89mm SGP film for laminated glass safety glass
- 40000 Square Inch / Square Inches per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal Other
You May Like
-
1.14mm SGP interlayer for laminated glass safety glass
-
1.52mm SGP interlayer for laminated glass safety glass by rolls
-
China hot sale SGP interlayer for safety glass
-
China SGP interlayer in stock . customized size
-
China SGP film for laminated glass safety glass
-
0.76mm SGP film for laminated glass safety glass
Product Details
| Brand Name | QUNAN | Place of Origin | China | |
| Model Number | QA-003 |
Product Description
Ionic interlayer(SGP) is a kind of ionic film composed of ethylene and methacrylate copolymer. It contains about 1% metal sodium ion. The bonding force between the film and glass is mainly the result of ionic bond. Therefore, the bonding strength between SGP and glass is much higher than that between PVB film and glass, and its hardness is 100 times stronger than that of traditional PVB ,The strength is 5 times of PVB.
Properties between SGP &PVB
physical parameters | SGP Interlayer | PVB Interlayer | Criterion of Detection |
tear(ing) strength | 135-145 KN/m （0.76mm) | 20-25 KN/m （0.76mm) | ASTM D-638 |
Tensile strength | 40-45 Mpa | 15-20 Mpa | ASTM D-638 |
elongation at break | 280-320% （0.76mm) | 220-250% （0.76mm) | ASTM-412 |
proportion | 0.95 | 1.066 | ASTM-792 |
Haze | << 1.0% | < 2% | JC/T 2166-2013 |
yellow index | < 1.0 | 6-10 | JC/T 2166-2013 |
refractive index | 1.5 | 1.5 | JC/T 2166-2013 |
light transmittance | 88% | 87% | JC/T 2166-2013 |
UV barrier | 99.9% | 97% | GB15763.3-2009 |
rate of water content | < 0.1% | 0.35-0.55% | SH/T1770-2010 |
Knock value | ≥7 | ≥7 | JC/T 2166-2013 |
thermal contraction | ≤2% | ≤8% | JC/T 2166-2013 |
