EPS200 CRI Diesel Fuel Common Rail Injector Tester Test Bench
US$ 3,200 - 3,400
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
DONGTAI
Place of Origin:
China
Model Number:
EPS200
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Leading Tech CRDI Test Bench DTS200 EPS 200 NTS200 XNS200US$ 3,200 - 3,400MOQ: 1 Piece -
CRDI TEST BENCH DTS200 EPS200 NTS200US$ 3,000 - 3,300MOQ: 1 Piece
-
Common Rail Injector Test Bench EPS205US$ 3,000 - 3,400MOQ: 1 Piece
-
EPS205 DTS205 Common Rail Injector Testing BenchUS$ 3,000 - 3,400MOQ: 1 Piece
-
EPS200 Common Rail Injector Test Bench EPS200US$ 3,000 - 3,400MOQ: 1 Piece
Brand Name
DONGTAI
Place of Origin
China
Model Number
EPS200
Power
Electronic
Usage
Auto Testing Machine
Product Description
EPS200 common rail injector test bench is our latest indepentent researched special device to test the performance of high-pressure common rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and displayed on computer screen(Electronic fuel delivery system). All data can be searched and saved. It adopts BOSCH original common rail pump to provide 0~2000 bar for rail pressure. The rail pressure can be adjusted automatically, and it also provide pressure overload protect. It can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology, steady performance, precise measurement and
>>>CHARACTERISTIC
1. Controlled by industrial computer in real time, Windows operating system.
2. Oil quantity is measured by sensor and displayed on 10.4'' tactile LCD screen;
3. More than 700 kinds of injecotors data can be searched and used.
4. It is installed BOSCH common rail pump to provide 0~2000 bar
5. Rail pressure can be tested in real time,
6. Provide pressure overload protect
7. Pulse and frequency of the injector can be adjusted.
8. Injection time can be set.
9. Protection function of short-circuit.
10. Precise measurement, easy operation, low noise.
11.Frequency converter inside to keep the RPM.
>>>FUNCTION
1.Test injector brands:BOSCH, SIEMENS, DELPHI, DENSO.
Piezo injector testing(option function)
2. Test 1 piece of injector.
3. Test the Leakage performance of common rail injector.
4. injection oil quantity and back oil quantity(pre-injection, Idling, emissions, full load)
5. Electronic fuel delivery measuring, automatic testing and detection.
6. Data can be searched and saved.
>>>TECHNICAL PARAMETER
1. output power:1.5KW
2. power voltage:220V 1phase
3. motor speed: 0-3000RPM
4. Oil pressure:0-2000bar
5. flow measure range: 0-600ml/1000times
6. flow measurement accuracy: 0.1ml
7. temperature control range: 40+-2
