BC-CR708 Water Meter Common Rail Test Bench
1. System Application:
The system is suitable for detection of BOSCH, DENSO, DELPHI and SIEMENS common rail injectors.
Such as CP1, CP2.CP3, HP3 series injector pump and the type of Electromagnetic injectors, It also can test 6 common rail injectors in one time.
2. Technical parameters
1, Main motor speed | 0-4000 r / min can be adjustable. |
2, Motor power | 7.5KW, 11KW, 15KW, 18.5KW optional. |
3, Fuel Injector open voltage Control range | 12V, 80V, 150V Control accuracy: phase adjustment |
4, Injector opening frequency Control | 0-1000HZ Control accuracy: 1HZ |
5, Fuel Injector Hold Time Control | 0-65535us |
6 Delivery Oil CountControl Control accuracy | 0-1000 times 1 times |
7, Fuel pressure control Control Control accuracy | 0-2000bar 1bar |
8, Electronic power | 3 PHASE 380V or 3 PHASE 220V |
3,Optional function:
1,Test piezo injector function.
2,Test HP0 pump function.
3, With Bosch DRV VALUE
4,Check the pump flow
We also have other model test bench,please point the model and check:
| Diesel Injection Pump test bench | Common Rail System Test Bench | Common Rail Tester and Electronic Pump Tester |
| 12PSB | PQ1000 | CR1000 |
| MINI12PSB | BCS300 | CR2000 |
| BC3000 | BC-CR708 | CR2000A or CRS3 |
| BCS619 | BC-CR819 | EUI/EUP tester and CAM BOX |
| BCS815 | CRS708 | VP44 tester |
| BC2001 | CR709 |
