Help CenterMotorized and Floor Mounted Microprocessor Control Single Specimens Direct Shear Test Machine Used for Soil Strength Test
Related Products
-
Automatic CBR Test Machine for California Bearing Ratio 50 kN LCD Touch ScreenUS$ 1,450 - 1,500MOQ: 1 Unit -
Automatic Computer Control Soil Direct Shear Test Machine With Analog Dial Indicators and Shear Box Shown for Soil StrengthUS$ 1,500 - 1,500MOQ: 1 Unit
-
ISO Standard High Pressure One-dimensional Soil Consolidation Testing Machines for Structures and Pavements.US$ 680 - 750MOQ: 1 Unit
-
ISO Standard Los Angeles Abrasion Test Machine Measure of Aggregate Toughness and Abrasion ResistanceUS$ 600 - 700MOQ: 1 Unit
-
Civil Soil Test Manual CBR California Bearing Ratio Measure of the Supporting Value of the Subgrade.US$ 400 - 480MOQ: 1 Unit
Application:
The test covers the determination of consolidated drained shear strength of a soil or sand material in direct shear. The Automatic Direct / Residual Shear Test Machine is supplied complete with load hanger, carriage assembly and an integral 9:1, 10:1 and 11:1 lever loading device. The apparatus is also motorized and floor mounted. The beam loading device, which is used to strengthen the vertical load on the shear box assembly, can hold up to 50 kg of weight. The total load on the specimen can reach up to 5 kN.
The machine is compatible with a range of square and round shear box assemblies. All shear box assemblies are designed to contain water that surrounds the specimen. The Assemblies consist of a shear box with a rigid wall square or round hole complete with a vertical loading pad grooved back face, a grooved retaining plate, 2 pcs. porous plates, 2 pcs. plane grids and 2 pcs. perforated grids.
Our direct shear test apparatus is a motorized dead weight testing machine designed for direct and residual shear testing on undisturbed and remolded soil specimens. The machine uses a 10:1 beam loading device to control confining pressures, a load cell with readout measures shear pressure and a displacement transducer to measure shear and vertical displacement.
Key Feature.
♦ Applicable standards: BS 1377; EN 1997-2; ASTM D3080
♦ Microprocessor control
♦ Rapid approach and return to start datum
♦ Fully variable speed, up to 9.99mm/min
♦ Reduced operator involvement
♦ Direct entry through keyboard
♦ Direct reading in engineering units
♦ Modular transducer system
♦ USB pen drive for unlimited storage capacity and TXT format data output
♦ Optional PC control via LAN port and dedicated software
♦ Sturdy shear box techno-polymeric carriage untouchable by corrosion
♦Adjustable speed and travel (forward and reverse) for residual shear test
♦ Number of cycles adjustable from 1 to 99
♦ Specific and independent data recording for consolidation and failure stages
Maximum vertical load (KPa) |
400 |
Pressure level (KPa) |
50,100,200,300,400 |
Corresponding weight weight (KPa) |
1.275,2.55,5.1,7.65,10.2 |
Lever radio |
1:12 |
Soil sample |
30cm2 x 2cm(H) |
Maximum horizontal shear force (KN) |
1.2 |
Power type |
electric |
Variable speed |
0.02,0.8,2.4mm/minute |
The displacement of the motor |
0.2mm/r |
Motor speed |
0.1,0.8.2.4r/min |
Voltage |
AC220V 50HZ |
Q: Are you trading company or manufacturer ?
A: We are the manufactory ,in this area for 20years
Q: How long is your delivery time?
A: If the products in stock, generally 5-10 days,.if stockout 15-20 days ,according to the quantity of order.
Q: Do you provide samples ? is it free ?
A: Yes, we could offer the sample for your test , but its not free.Hope to understand the high cost of products for high quality
Q: What is your terms of payment ?
A: Payment amount<=1000USD, 100% in advance. Payment amount >=1000USD, 30% T/T in advance ,balance as the B/L copy
