DJXS-05 Corrosion analyzing instrument (scene test)
I. Application:
Corrosion reduces the rebar's section in the construction concrete and the force of adhesion between the rebar and the concrete, which directly influence the construction’s safety and wear. Generally, it must measures the rebar corrosion state when examine the structural identification and reliability.
Application:
Measuring the corrosion state of the construction concrete caused by multi factor, exclude the potential safety hazard caused by it.
II. According Standard:
Technical standard for inspection of building structure of the People’s Republic of China GB/T50344-2004
US standard, Japan Standard, German Standard
III. Feature:
1.Siphoning type electrode(Earthlong Patent), really test each side effectively.
2. Easy operation; Super test area; Result display two mode data and Image.
3.Read quickly; Data error ±1mv;
4. Nine gray scientific grade; Color display of the corrosion range.
5. Special analysis software; reporting auto and drafting electric potential diagram.
IV. Main Specification:
|
Test electric potential |
±1000mv |
|
Test precision |
±1mv |
|
Reading Storage |
228000 readings |
|
Test Area |
Max 1600m2 |
|
Set point distance |
1—60cm optional |
|
Work temperature |
0—40°C Humidity:<85% |
|
Power |
9VDC(Six AA batteries ); Work time >30 hour |
|
Host Size |
225×180×80(mm);Probe:φ30×180(mm) |
Stable performance, best price, good quality , good after-sales service
Usage field: laboratory products
